CONTROL BOX REPLACEMENT PARTS LIST
30
X9 REPLACEMENT PARTS LIST
Item X9-Number
1 X9002
2 X9004
3 X9006
4 X9008
5 X9010
6 X9012
7 X9014
8 X9016
9 X9018
10 X9020
11 X9022
12 X9024
13 X9026
14 X9028
15 X9030
16 X9032
17 X9034
18 X9035
Item X9-Number
A X9036
B X9038
C X9040
D X9042
E X9044
F X9046
G X9048
H X9050
I X9048
J X9048
If you are uncertain about a specific part you
may need, please call us for assistance:
1-800-708-8848
Part Description
X9 Operator Cover (Removable)
X9 Cover Bolt (x2)
X9 Key
X9 Lock
X9 Manual Release Handle
X9 Limit Plate
X9 Limit Switch (x2)
X9 Stroke Screw Shaft
X9 Stroke Pin Assembly
X9 Mechanical Stop (x2)
X9 Motor Assembly / Motor Housing
X9 Motor Cable
X9 Rear Bracket
X9 Rear Bracket Securing Bolt Assembly
X9 Front Bracket
X9 Front Bracket Securing Bolt Assembly
Warning Sign
Dual Operator Kit
Part Description
Step-Down Transformer
X9 Control Board
14-PIN Terminal Board
T4 Amp Fuse
Input Power Terminal On/Off Switch
F16 Amp Fuse
F3 Amp Fuse
Eagle Transmitter
Control Box Assembly (Complete)
Plastic Control Box ONLY
X9 Swing Rev - H
