DIP-SWITCH DESCRIPTIONS

2 3 5 6
1 4
C BSC BSA FT1 FT2 J1 J2 PC PA PED STP P/P
1 2 3 4 5
1 2 3 4 5
MOTOR MOTOR
1 LIMITS 2 LIMITS
Turn DIP-switch OFF for any CONNECTED device will INCLUDE them in Programming.
Turning DIP-switch ON will EXCLUDE the corresponding terminal input.
Switch Set
ON
OFF
Closing sensing edge installed on terminal #2-BSC.
1
BSC #1
ON
Excludes the closing sensing edge input on terminal #2-BSC.
ON
NOTE: Terminal #2-BSC must remain disconnected.
1
ON
OFF
Opening sensing edge installed on terminal #3-BSA.
2
BSA #2
ON
Excludes the opening sensing edge input on terminal #3-BSA.
ON
NOTE: Terminal #3-BSA must remain disconnected.
2
ON
OFF
CLOSING Photocell has been installed on terminals #4-FT1 &
FT1 #3
3
ON
12
Excludes the closing photocell input on terminals #4-FT1 &
ON
NOTE: Terminals #4-FT1 &
3
ON
OFF
Photocell has been installed on terminal #5-FT2.
4
FT2 #4
ON
Excludes the photocell input on terminal #5-FT2.
ON
NOTE: Terminal #5-FT2 must remain disconnected.
4
ON
OFF
Device has been installed on terminals #6-J1 &
J1 #5
5
ON
2
Excludes the J1 input on terminals #6-J1 &
ON
NOTE: Terminals #6-J1 &
5
ON
OFF
Device has been installed on terminals #7-J2 &
J2 #6
6
3
ON
Excludes the J2 input on terminals #4-J2 &
ON
NOTE: Terminals #7-J2 &
6
ON
OFF
Stop Button has been installed on terminal #11-STP.
7
STP #7
ON
Excludes the Stop Button input on terminal #11-STP.
ON
NOTE: Terminal #11-STP must remain disconnected.
7
11
7 8 9 10 12 13
13-PIN Terminal On Circuit Board
C
6 7 8 9 10 11 12 13
6 7 8 9 10 11 12 13
+ + +
MAG LOCK 24VDC 24 COM
Description
12
must remain disconnected.
