- Page 1 Sliding Gate Eagle-2000 Series Eagle-1000 Series ntrol Systems, Inc. Distributed by: AFW Access Systems 305-691-7711 • www.AnchorMiami.com Phone: Operator Installation and Instructions for the Eagle-2000 and Eagle-1000 Series. UL325 and UL991 Compliant...
-
Page 2: Table Of Contents
Page 24 Operator Parts List / Eagle-2000 & Eagle-1000 Page 25 © 2002 Eagle Access Control Systems, Inc. All rights reserved. No part of this manual may be reproduced in any means: graphics, electronics, or mechanical, including photocopying without the expressed written permission of the publisher. Materials, components and specifications are subject to change without notice. -
Page 3: Ul Listings
UL Listings Gate Operators Installation Instructions Install the gate operator only when: The operator is appropriate for the construction and the usage Class of the gate. All openings of a horizontal slide gate are guarded or screened from the bottom of the gate to a minimum of 4 feet (1.2 m) above the ground to prevent a 2 ¼... - Page 4 UL Listings Essential Safety Procedures WARNING - TO REDUCE THE RISK OF INJURY OR DEATH - READ AND FOLLOW ALL INSTRUCTIONS: Never let children operate or play with gate controls. Keep the remote control away from children. Always keep people and objects away from gate while the gate is in operation. NO ONE SHOULD CROSS THE PATH OF A MOVING GATE.
-
Page 5: Installing The Warning Sign / Precautions
____________________ CAUTION! Be sure to read and follow all the Eagle Access Control Systems, Inc. and UL instructions before installing and operating any Eagle Access Control Systems, Inc. products. Eagle Access Control Systems, Inc. is not responsible for any improper installation procedures caused by installer or user failing to comply with local building codes. -
Page 6: Instructions On Gate Posts
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Instructions on Gate Posts mportant Notice! Because the coasting distance may vary due to change in temperature, Eagle Access Controls does NOT recommend the installation of a stop or catch post in front of the gate path as shown in Example A. -
Page 7: Methods Of Installation
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Methods of Installation CAUTION! It is highly recommended to install "over travel stops" at both ends of the gate rail in any type of installation in order to prevent derailing. -
Page 8: Mounting Operator(S) To Concrete Pads
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Mounting Operator(s) To A Concrete Pad CAUTION! Be sure that the operator is installed in a level and paralleled position and is properly secured. Improper installation could result in property damage, severe injury, and/or death. -
Page 9: Connecting The Power
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Connecting The Power CAUTION! Be sure that the circuit breaker for the line input power is turned off before connecting the input power to the unit. Connect 120 VAC, 15A, 60HZ, line input power to the wires provided in the power switch junction box located near the bottom of the operator. -
Page 10: Two Way Adjustable Reverse Sensors / Erd
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Two Way Adjustable Reverse Sensor / ERD CAUTION! Only a qualified service technician must make all adjustments to the senso The Eagle Diamond Control Board has two separate pots for adjusting sensitivity. -
Page 11: The Feature Selector
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ The Feature Selector The selector uses an eight-station switch system that allows selection of the standard features and customized installation settings. The switch description is as follows: Note: The power should always be turned off when designating feature selector switches... - Page 12 Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ The Feature Selector (Continued) Switch 4: Reverse Loop - Sets the reverse loop to be normally open or to normally close. It is useful in Fail-Safe applications. Switch 5: One Pass (On/Off) - This tailgating feature works with the reverse loop to allow only one car to pass.
-
Page 13: Master And Slave Operation
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Master and Slave Operation Important: Be sure that the 120VAC power (for the Master and the Slave) are connected to the same circuit breaker. Use 20GA stranded wire for Master/Slave communication... -
Page 14: Slave Control
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Slave Control Options Switch #1 must be set to the Slave or to the "off" position. Switch #2 must be set to the "open left" or to the "open right" position. -
Page 15: Describing The Output Connections
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Describing The Output Connections Entire Output Section MAG Lock Solenoid Connections (24 VDC) The Eagle Diamond Control Board provides a 24VDC and relay output for MAG Locks or Solenoids. Alarm (12 VDC) -
Page 16: Connecting The Accessories
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Connecting The Accessories With the exeption of the MAG Lock, all of these accessories can be installed on the Master or Slave operator. Reverse Key Lock Box Loop Fire Lock Box... -
Page 17: Description Of Inputs
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Description of Inputs Reverse Loop - Momentary or Continuous Signal Key / Keypad (Continued) This input is active only when the gate is closing or when Timer Off - Momentary Input its fully open. -
Page 18: Receiver Connections
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Receiver Connections The receiver terminal is mounted on the control box for easy installation and is pre-wired for a 3-wire or 4-wire receiver. When installing 4-wire, 4-Wire Connections use terminals 1 & 2. -
Page 19: Emergency Releases
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Emergency Releases The Fail Secure System Release Instructions: Turn off the power - Failure to do so can result in serious injury or death. Insert crank into the crank aperture... -
Page 20: Mounting The Secondary Entrapments
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Mounting The Secondary Entrapment Note: Eagle Access Control Systems, Inc. recommends the installation of Edge Sensors on all sliding gate operator systems. All Contact Sensors Are Connected To Edge Sensor Inputs... -
Page 21: Control Board Led Indicators
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Control Board LED Indicators 1. Power On 5. Key / Keypad 10. Receiver 15. Overload 2. Master / Slave 6. Stop 11. Close Limit 16. Active Communication 7. Exit / Open 12. -
Page 22: Troubleshooting
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Troubleshooting SYMPTOMS PROBABLE CAUSES REMEDY Gate stops and reverses (A) Gate operator is not plumb (A) Remount operator or chain direction in mid travel and the and level. brackets. OVERLOAD LED remains ON. -
Page 23: Parts Breakdown / Eagle-2000
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Parts Breakdown / Eagle-2000 Entire Kit - E300 No Weld Chain Assembly E307 E305 E555 E293 E306 E525 E333 E292 Entire Assembly Kit E194 E106 LIMIT SWITCH E132 ASSEMBLY E107... -
Page 24: Parts Breakdown / Eagle-1000
Slide Gate Operators / Eagle-2000 Series / Eagle-1000 Series ____________________ Parts Breakdown / Eagle-1000 E525 E555 E293 E444 E292 Entire Assembly Kit E106 LIMIT SWITCH E198 ASSEMBLY E132 Entire Kit - E300 E107 No Weld Chain Assembly E108 E109 E133... -
Page 25: Operator Parts List / Eagle-2000 & Eagle-1000
