Main Illustrations—All Tools
All housing screws
screwed in completely.
T=2.5 Nm max.
103
70
71
75
7
Motor Assembly
81
Greenlee / A Textron Company
102
77
72
78
40
83
82
Battery-powered In-line X Tools
Screw on hand-tight.
Then turn out until
the radial hole is
free to screw in the
anti-twist screw.
T=1 Nm
T=12 Nm max.
6
73
5
T=2 Nm max.
29
T=12 Nm
T=1 Nm
88
87
84
86
85
4
4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
T=40 Nm
80
2
T=2 Nm
3
19
76
89
101
4
68
69
79
100
