Greenlee GATOR EK6IDLX Service Manual page 14

Head and Ram Illustration and Parts List—EK622L
17
17
8
15
7
21
21
19
11
10
20
18
Key Part No. Description
52054798 Head and ram (includes 3–24)
3 52055797 Ram ........................................................... 1
4 52080214 Adapter disk .............................................. 2
5* O-ring (included in 50047957) ................... 1
6 50058398 Compression spring .................................. 1
52055866 Pin kit (includes 7–9, 17)
7 Spring ........................................................ 2
8 Pin ............................................................. 1
9 Pin ............................................................. 1
52055867 Die retainer kit (includes 10, 11, 18–22)
10 Die retainer ................................................ 2
11 Compression spring .................................. 4
12 50041681 Screw ........................................................ 2
13 50058304 Bottom crimp head ................................... 1
14 50121693 Latch ......................................................... 1
Greenlee / A Textron Company
9
14
7
T=2 Nm
12
19
11
22
18
16 23
T=2 Nm
24
11
22
Battery-powered In-line X Tools
6
4
5
13
17
12
17
Qty Key Part No.
15 50121731
16 50121715
17
18
19
20
21
22
52055865
23
24
25 52020648
26*
27*
14
4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
26
25
3
4
Description
Top die holder............................................ 1
Bottom die holder ..................................... 1
Retaining ring ............................................ 4
Die release button ..................................... 2
Die retainer ................................................ 2
Roll Pin ...................................................... 2
Die release button ..................................... 2
Locking pin ................................................ 2
Die holder kit (includes 23, 24)
Threaded stud ........................................... 1
Pin ............................................................. 1
Piston cup ................................................. 1
Backup ring (included in 50047957) .......... 1
O-ring (included in 50047957) ................... 1
27
Qty
