Greenlee GATOR EK6IDLX Service Manual page 18

Head and Ram Illustration and Parts List—ESG45L
18
12
9
8
Key Part No. Description
52080213 Head and ram (includes 8–21)
1 O-ring (included in 52054906) ................... 3
2 Piston backup ring
(included in 52054906) .............................. 1
3 Screw, M3x6 mm button hd cap
(units without item 22) ............................... 2
*
52057106 Screw, M3x5 mm socket hd cap
(units with item 22) .................................... 1
4 50058258 Compression spring .................................. 2
5 Adapter disk .............................................. 2
6 O-ring (included in 52054906) ................... 1
7 50103962 Piston ....................................................... 1
8 Stationary blade ........................................ 1
9 Cutting blade ............................................. 1
10 Screw ........................................................ 4
11 Snap ring ................................................... 2
Greenlee / A Textron Company
3*
21
15
19
14
20
17
10
Battery-powered In-line X Tools
3
5
6
13
3
16
11
Qty Key Part No.
12
13
14
15
16
17
18
19
20
21
22 52065822
23 52065824
24 52065826
25 52065825
18
4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
7
22
4
Description
Cutting head .............................................. 1
Cutting head base ..................................... 1
Pin, 8 x 20 ................................................. 1
Sleeve ........................................................ 2
Pin ............................................................. 1
Guide plate ................................................ 1
Side plate .................................................. 2
Pull pin....................................................... 1
Brace plate ................................................ 1
Screw ........................................................ 1
Stroke adjustor (used in models
with M3x5 mm screw) ............................... 1
Plate kit (includes 12, 13, 17, 18, 20) ........ 1
Blade kit (includes 8, 9, 14) .........................
Fastener kit (includes 3, 5, 10, 11, 14-16, ..
19, 21)
1
2
Qty
