Sunricher SR-2819T8 Manual

RF RGBW Remote Controller
Important: Read All Instructions Prior to Installation
Function introduction
Touch color wheel, touch to
choose RGB color tone
Click to switch CW,
NW, WW mixed by RGB
R
Speed down under dynamic mode S-
Press and hold down to
B-
decrease light intensity of RGB
Built-in 10 dynamic modes,
P- is previous mode,P+ is next mode.
1
5
Indicator: indicate the state of
remote control
R/G/B/W 4 channels.
Click to switch on/off each channel;
Press and hold down to increase/
G B W
decrease light intensity of each
channel
W+ S+ Speed up under dynamic mode
Press and hold down to increase
B+
light intensity of RGB
P- P+
8 zones
2 3 4
Click to choose the zone/zones,
Press and hold down to turn on/off
6 7 8
corresponding zone
Front side
4.5V(3xAAA battery)
Back side
Product Data
09.289T8.04168
Output
Operation Frequency
Power Supply
Operating temperature
Relative humidity
Dimensions
Safety & Warnings
• This device contains AAA batteries that shall be stored and disposed properly.
• DO NOT expose the device to moisture.
Pair with RF receiver(Method 1)
R G B W
S- W+ S+
B- B+
P- P+
1 2 3 4
5 6 7 8
Pair with RF receiver(Method 2)
R G B W
S- W+ S+
B- B+
P- P+
1 2 3 4
5 6 7 8
• High sensitive & high stable, fast & precise color control.
RF signal
• Enable to control 8 zones separately.
• 10 changing modes.
869.5/916.5/434MHz
• Compatible with all universal series RF receivers
4.5V(3xAAA battery)
• 1 receiver can be paired by max 8 different remote controls.
• Waterproof grade: IP20
0-40°C
8% to 80%
131.4x43.8x24.3mm
Step 1:Do wiring the RF receiver according to wiring diagram(please refer to the
instruction of RF receiver that you would like to pair with.
Step 5:Touch the color wheel, LED lights connected with the RF receiver flicker
once means the receiver is paired with zone 4 successfully.
Step 2:Click ON/OFF button to activate the remote
RF LED Receiver
Learning Key
Step 3:Click the "Learning Key" button on RF receiver or re-power on the receiver
three times continuously to set it into pairing status
Step 4:Choose and click a zone number(e.g. zone 4)
Step 1:Do wiring the RF receiver according to wiring diagram(please refer to the
instruction of RF receiver that you would like to pair with.
RF LED Receiver
Learning Key
Step 3:Power off and power on the receiver
Step 2:Click ON/OFF button to activate the remote
Step 4:Choose and click a zone number(e.g. zone 4) twice, then press and hold it
continuously and quickly within 10 seconds, LED lights connected with the RF receiver
flicker once means the receiver is paired with zone 4 successfully.
