HDMI video inputs — Four female HDMI connectors for HDMI compliant audio and
D
video input (numbered 3 through 6 on the rear panel). Connect an HDMI source device
using standard HDMI cables.

Output

HDMI video output — Connect an HDMI display device for output from the selected
E
input.

Control Devices

Contact In and Tally Out — Six 3.5 mm, 3-pole captive screw connectors for
F
automatic input switching and tally indication using Extron Show Me cables.
When a connected contact is grounded, the corresponding input is selected. At the
same time, the tally output closes causing the Show Me LED on the connected cable to
light (see
NOTE: For Show Me cables, the ground pin connection is optional.
The six contacts are mutually exclusive so that only one
input is selected at a time (see the image on the right
showing Contact In and Tally Out connector wiring).
NOTE: Do not tin the leads. Tinned wires are not as
secure in the connector and could be pulled out.
+V Port — 3-pole, 3.5 mm captive screw connector. The
G
three pins constantly output +5 VDC, 200 mA total
(shared between pins) to provide power for external tally
LEDs (see the image on the right showing +V connector
wiring).
NOTE:
power connectors.
RS-232 remote — 3-pole, 3.5 mm captive screw
H
connector for a host computer or a controller using
Simple Instruction Set (SIS) commands or the PCS
software (see the image on the right showing RS-232
connector wiring).
An IP Link driver allows Extron IPL and MediaLink
devices to control the MPS 601 from the RS-232
remote connector.
USB configuration port (front panel) — (see
c
Female USB mini B jack used for configuration of the switcher and firmware upgrades
(see Updating Firmware
Contact Closure and Tally Output Application Diagrams
Do not connect "Show Me" cables to the +V
on page 49).
on page 7).
Do not tin
the wires!
Do not tin
the wires!
RS-232
Device
Transmit (Tx)
Do not tin
Receive (Rx)
the wires!
_
Ground ( )
Front Panel Features on page 11)
