Features

•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Supports computer and video resolutions up to 4K — Resolutions up to
4096x2160/30 with 4:4:4 chroma sampling at 8 bits of color, including 1080p/60 and 2K.
NOTE: 4K60 video at 4:2:0 chroma sampling is not supported.
Presentation System Integration — Integrates HDMI, RGB, and audio sources into
presentation systems.
Inputs — Includes four female HDMI and two female 15-pin HD connectors for video;
two female 3.5 mm TRS connectors for analog audio.
Output — Includes one female HDMI connector.
Four HDMI inputs and two RGB inputs — Provides switching between HDMI and
analog video sources.
Digitizes analog video and audio signals — Provides a single video format and
cable connection to the display.
HDMI audio embedding — Embeds analog input audio signals onto the HDMI output
signal.
EDID Minder — Automatically manages EDID communication between connected
devices ensuring that all sources power up properly and reliably output content for
display.
Key Minder — Continuously verifies HDCP compliance for quick, reliable switching.
Support for computer-video to 1920x1200, including HDTV 1080p 60 Hz and 2K.
Supported HDMI specification features — Include data rates up to 6.75 Gbps,
Deep Color up to 12-bit, 3D, Lip Sync, and HD lossless audio formats.
HDCP authentication and signal presence LED indicators — Front panel LED
indicators provide real-time feedback and monitoring of key performance parameters.
HDMI to DVI interface format correction — Automatically reformats HDMI source
signals for output to a connected DVI display.
Automatic input cable equalization to 50 feet (15 meters) at 1080p 60 Hz with
8-bit color when used with Extron HDMI Pro Series cable — Actively conditions
incoming HDMI signals to compensate for signal loss when using long cables, low
quality cables, or source devices with poor HDMI signal output.
Control for video and audio muting — Mutes video and audio signals by external
contact closure or RS-232 control.
Audio input assignment — Provides integration flexibiity. In normal operation, the
analog audio inputs follow the corresponding RGB input. Alternatively, they can be
assigned to follow preset groups of RGB and digital inputs. Grouped inputs can share
a common analog audio input. The HDMI output can be set to pass incoming digital
audio, embed the analog audio, or automatically embed the analog audio when no
digital audio is detected.
Powers on the HDMI output — Provides +5 VDC, 200 mA.
Front panel security lockout — Prevents unauthorized use in non-secure
environments. In lockout mode, a special button combination is required to operate the
switcher from the front panel controller.
Extron Product Configuration Software (PCS)— Can conveniently configure
multiple products using a single software application.
Multiple control options — Includes front panel, RS-232, contact closure, and
auto-input switching.
Auto-input switching — Switches to the highest- or lowest-numbered input
(selectable) with an active video signal.
