3 Installing the idOil-SLU
sludge sensor
The sensor must be submerged at the desired installation depth when
the liquid is at the separator's standard liquid level (L). Notice manu-
facturer´s instructions for oil separators.
1 Sludge sensor idOil-SLU
A Air
B Oil
C Water
D Sludge
L Standard liquid level
S Alarm trigger
S Alarm switching point
point
X Alarm level
(max sludge level)
S
