Connection with three sensors, two relays

and supply voltage

1 Supply voltage (connectors L1, N, PE)

2 Sensor connections (connectors 9-14)

3 Relay 1 connection (connectors 3,4,5)

Relay 2 connection (connectors 6,7,8)

4 Extension of cable with LCJ cable connectors

5 Protection cover
