Front Panel Overview

1
11 12
Table 1 Front Panel Description
No. Description
1 Measurement Menu Softkeys
2 LCD
3 Function Menu Softkeys
4 Multifunction Knob
Common Operation Keys
5
6 CLEAR
7 AUTO
8 RUN/STOP
9 SINGLE
10 Help/Print
[1]
Note : Only applicable to DS1000Z Plus.
[2]
Note : Only applicable to digital oscilloscopes with source channels.
8
2
13
Figure 10 Front Panel Overview
3 4 5
14 15 16 17
No. Description
11 Power Key
12 USB Host Interface
13 Digital Channel Input Interface
14 Analog Channel Input Interface
15 Logic Analysis Control Key
16 Signal Source
17 VERTICAL Control
18 HORIZONTAL Control
19 TRIGGER Control
Probe Compensation Signal
20
Output Terminal/Ground Terminal
6 7 8 9 10
18 19 20
[1]
[2]
