MCA 121 EtherNet/IP
Service Code
Class
0Eh Yes
01h Yes
10h No
4Bh No
Table 8.15: Services supported
Class ID 0x10 Parameter Group Object
Attribute Access
Rule
1 Get Group Name String
2 Get Number of group members
3 Get 1st group parameter (000-099) UINT
4 Get 2nd group parameter (100-199) UINT
... Get ...
n+2 Get nth group parameter
Table 8.16: Instance Attributes
Class ID 0x64 – 0xC7 Danfoss Objects
The CIP Class ID 100 to 199 (0x64 to 0xC7) gives access to all drive parameters.
Class (decimal)
100
101
102
103
104
105
106
107
108
109
110
111
...
199
The class Instance and Attribute acts in the following way:
- 100 added to the parameter group = the value for the class.
- 100 added to the remaining parameter number = the value for the instance.
- 100 added to the array index of the parameter = the value for the attribute
Examples: (fictitious parameters)
- Parameter 0-01 [index 0] = Class 100; Instance 101; Attribute 100
- Parameter 1-00 [index 0] = Class 101; Instance 100; Attribute 100 - Parameter 2-59[index 0] = Class 102; Instance 159; Attribute 100
- Parameter 5-34[index 3] = Class 105; Instance 134; Attribute 103
- Parameter 6-54 [index 9] = Class 106; Instance 154; Attribute 109
- Parameter 10-01 [index 0] = Class 110; Instance 101; Attribute 100
All values in decimal.
All parameters are accessed in the Active setup (par. 0-10
Supported Service Name
Instance
Yes Get_Attribute_Single
Yes Get_Attributes_All
Yes Set_Attribute_Single
Yes Get_Enum_String
Name Data Type
SHORT_STRING
UINT
UINT
UINT
Active Set-up )
®
MG.90.J2.02 - VLT is a registered Danfoss trademark
Description of Service

returns contents of specified attribute

returns predefined listing of object attributes

modifies attribute

reads enumerated strings from parameter instance
Description
represents group name
amount of parameters in group
instance number of Parameter Object
instance number of Parameter Object
...
instance number of Parameter Object
Danfoss Parameter range
0-01 - 0-99
1-00 – 1-99
2-00 – 2-99
3-00 – 3-99
4-00 – 4-99
5-00 – 5-99
6-00 – 6-99
7-00 – 7-99
8-00 – 8-99
9-00 – 9-99
10-00 – 10-99
11-00 – 11-99
...
99-00 – 99-99
8 Appendix
Contents
Name of Group from Drive
value of n
variable
variable
variable
variable
8
57
