4 How to Configure

4.1.1 IP Settings
All IP-related parameters are located in parameter group 12-0*:
12-00 IP Address Assignment
12-01 IP Address
12-02 Subnet Mask
12-03 Default Gateway
12-04 DHCP Server
12-05 Lease Expires
12-06 Name Servers
12-07 Domain Name
12-08 Host Name
12-09 Physical Address
The MCA 121 option offers several ways of IP address assignment.
Setting up drive with manual assigned IP address:
Par. Name
12-00 IP Address Assignment
IP Address
12-01
Subnet Mask
12-02
Default Gateway
12-03
*= Class C IP address example. Any valid IP address can be entered.
NB!
A power-cycle is necessary after setting the IP parameters manually.
Setting up drive with automatic (BOOTP/DHCP) assigned IP address:
Par. Name
12-00 IP Address Assignment
IP Address
12-01
Subnet Mask
12-02
Default Gateway
12-03
By IP address assigned by DHCP/BOOTP server, the assigned
Server , the IP address of the found DHCP or BOOTP server is displayed. For DHCP only: The remaining lease-time can be read-out in par. 12-05
Expires .
Physical Address
Par. 12-09, reads out the MAC address of option, which is also printed on the label of the option. If using fixed leases together with
DHCP or BOOTP, the physical MAC address is linked with a fixed IP address.
NB!
If no DHCP or BOOTP reply has been received after 4 attempts (e.g. if the DHCP/BOOTP server has been powered off), the option will
fallback to the last good known IP address.
Value
[1] DHCP/[2] BOOTP
Read only
Read only
Read only
IP Address Subnet Mask
and
®
MG.90.J2.02 - VLT is a registered Danfoss trademark
Value
[0] MANUAL
192.168.0.xxx*
255.255.255.0*
optional
can be read out in par. 12-01 and 12-02. In par. 12-04
4 How to Configure
4
DHCP
