MCA 121 EtherNet/IP
[3] * Logic OR
NB!
This parameter is only active when par. 8-01
8-55 Set-up Select
Option:
[0] Digital input
[1] Bus
[2] Logic AND
[3] * Logic OR
NB!
This parameter is active only when par.8-01
8-56 Preset Reference Select
Option:
[0] Digital input
[1] Bus
[2] Logic AND
[3] * Logic OR
NB!
This parameter is active only when par.8-01

6.2 Parameter Group 12-**

6.2.1 IP Settings
12-00 IP Address Assignment
Option:
[0] * Manual
[1] DHCP
[2] BOOTP
Activates the Reverse command via the fieldbus/serial communication port OR via one of the digital
inputs.
Control Site is set to [0]
Function:
Select control of the frequency converter set-up selection via the terminals (digital input) and/or via
the fieldbus.
Activates the set-up selection via a digital input.
Activates the set-up selection via the serial communication port or fieldbus option.
Activates the set-up selection via the fieldbus/serial communication port, AND additionally via one
of the digital inputs.
Activate the set-up selection via the fieldbus/serial communication port OR via one of the digital
inputs.
Control Site Digital and control word
is set to [0]
Function:
Select control of the frequency converter Preset Reference selection via the terminals (digital input)
and/or via the fieldbus.
Activates Preset Reference selection via a digital input.
Activates Preset Reference selection via the serial communication port or fieldbus option.
Activates Preset Reference selection via the fieldbus/serial communication port, AND additionally
via one of the digital inputs.
Activates the Preset Reference selection via the fieldbus/serial communication port OR via one of
the digital inputs.
Control Site Digital and control word
is set to [0]
Function:
Selects the IP Address assignment method.
IP-address can be set in par. 12-01 IP Address.
IP-address is assigned via DHCP server.
IP-address is assigned via BOOTP server.
®
MG.90.J2.02 - VLT is a registered Danfoss trademark
Digital and control word .
.
.
6 Parameters
