MCA 121 EtherNet/IP
CIP Malfunction
Code
0 No alarm
0 unused
4210 Drive over temperature
2240 Earth fault
0 unused
8100 Controlword timeout
2310 Overcurrent
8302 Torque limit
4310 Motor thermistor
4310 Motor ETR over temp
2311 Inverter overloaded
3220 DC Link undervoltage
3210 DC Link overvoltage
2130 Short circuiting
2213 Inrush fault
3130 Mains phase loss
5210 AMT fail
1000 Live zero fault
6100 Internal fault
7110 Brake resistor power limit
3300 Motor phase U missing
3300 Motor phase V missing
3300 Motor phase W missing
8100 Fieldbus Comm. fault
5112 24V supply fault
3100 Mains failure
5110 1,8V supply fault
7110 Brake resist. short circ.
7110 Brake chopper fault
0 unused
0 unused
0 unused
0 unused
Table 8.6: Attribute 13 "Fault Code"
Mir = Minor Recoverable
Mar = Major Recoverable
Mau = Major Unrecoverable
Service Code
0Eh Get_Attribute_Single
10h Set_Attribute_Single
05h Reset
Table 8.7: Services supported
NB!
Class ID 0x29 is only available if ODVA profile is selected in par.8-10
Meaning VLT-Code Alarmword
0000 0000
0000 0001
0000 0002
0000 0004
0000 0008
0000 0010
0000 0020
0000 0040
0000 0080
0000 0100
0000 0200
0000 0400
0000 0800
0000 1000
0000 2000
0000 4000
0000 8000
0001 0000
0002 0000
0004 0000
0008 0000
0010 0000
0020 0000
0040 0000
0080 0000
0100 0000
0200 0000
0400 0000
0800 0000
1000 0000
2000 0000
4000 0000
8000 0000
Service Name
®
