Danfoss VLT MCA 121 EtherNet/IP Manual page 48

7 Troubleshooting
Bit (Hex)
00000001
00000002
00000004
00000008
00000010
00000020
00000040
00000080
00000100
00000200
00000400
00000800
00001000
00002000
00004000
00008000
00010000
00020000
00040000
7
00080000
00100000
00200000
00400000
00800000
01000000
02000000
04000000
08000000
10000000
20000000
40000000
80000000
48
Warning word 2 (Par. 16-93)
Start Delayed
Stop Delayed
Clock Failure
Firemode was active
Reserved
No Flow
Dry Pump
End of Curve
Broken Belt
Discharge high
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
KTY warning
Fans warning
ECB warning
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
PTC thermistor
Reserved
MG.90.J2.02 - VLT
Bit (Hex)
00000001
00000002
00000004
00000008
00000010
00000020
00000040
00000080
00000100
00000200
00000400
00000800
00001000
00002000
00004000
00008000
00010000
00020000
00040000
00080000
00100000
00200000
00400000
00800000
01000000
02000000
04000000
08000000
10000000
20000000
40000000
80000000
®
is a registered Danfoss trademark
MCA 121 EtherNet/IP
Extended status word (Par.
16-94) FC 200 only !!
Ramping
AMA Running
Start CW/CCW
Slow Down
Catch Up
Feedback high
Feedback low
Output current high
Output current low
Output frequency high
Output frequency low
Brake check OK
Braking max
Braking
Out of speed range
OVC active
AC brake
Password Timelock
Password Protection
Reference high
Reference low
Local Ref./Remote Ref.
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
