    RX: FEDERAL LAW RESTRICTS THIS DEVICE TO INDICATIONS FOR USE: SALE BY OR ON THE ORDER OF A DENTIST The AEU-5000 can be used for a wide range of dental procedures including endodontic surgeries, such as drilling INFORMATION CONCERNING THE ACCURACY AND...
  • Page 3: Introduction

    Your new Aseptico AEU-5000 System is one of the finest general dental electric motor systems available to the dental profession. The System features a high-speed electric sensor-less micromotor, an intuitive user interface, an easy to read LCD display, and an air/electric converter which enables use with an existing air and water media ongratulations supply.
  • Page 4: Safety Precautions

    • Handpieces should only be attached when the motor has stopped running. WARNING: Do not install where there is a risk of an explosion. The AEU-5000 is not intended for operation in the presence of flammable anesthetics or gases. WARNING: Always comply with the endodontic handpiece and file manufacturer’s instructions...
  • Page 5 WARNING: Always use irrigating coolant when using high-speed handpieces. WARNING: Do not use the AEU-5000 for implant surgery or where the cooling air can access an open wound. CAUTION: The AEU-5000 is not recommended for use with endodontic files that have torque limit requirements less than 100 g-cm.
  • Page 6: Setting Up The Unit

    CHIP WATER 2. Attach the 4-hole handpiece tubing connector CHIP AIR from the office dental system to the receptacle on the back of the AEU-5000 console (refer to INPUT symbol in Figure 2). (EXHAUST) Fig. 2 - Console Back 4-HOLE...
  • Page 7 7. Foot Control: The existing foot control Fig. 8 - Under Counter Installation used to operate the office dental delivery system will now operate the AEU-5000. For variable-pressure foot control, note that the motor speed is proportional to the air pressure delivered within a 20 PSI (1.36...
  • Page 8: Control Panel Functions

    The intuitive user interface makes it easy to enabled. The available ratio options are: begin using your new AEU-5000. The system 1:5, 1:2, 1:1, 5:1, 8:1. operation section follows these control panel NOTE: The user can reprogram the unit to function descriptions.
  • Page 9 Figure 10 are accurate only when the icon will blink as the adjustments are correct handpieces are used. made. To exit the adjustment mode, press Fig. 10 - AEU-5000 Speed Ranges and release the Illumination button. 7 MOTOR DIRECTION Selector w/Display: 10,000 - 200,000...
  • Page 10: Operation

    OPERATION: B. PRESET OPERATION - The AEU-5000 After the AEU-5000 System has been set up and the user has become familiar with its is shipped with five preprogrammed factory Presets for each ratio (see Figure 12, page control panel functions, the unit is ready to 10).
  • Page 11: Customizing Ratios & Presets

    (see Figs. 11a & 11b). After 20 minutes of motor inactivity, the Fig. 11a - Enabled AEU-5000 automatically enables an energy- saving Sleep Mode which turns off the Display. When in this mode, three square symbols will blink consecutively across the Fig.
  • Page 12 OPERATION - Cont'd Figure 12 - Factory Default Presets PRESET SPEED ENDO MODE DIRECTION TORQUE HANDPC RATIO (RPM) (8:1 Ratio Only) 200,000 100 % — 150,000 100 % — 150,000 50 % Torque Limit — 100,000 100 % — 100,000 50 % Torque Limit —...
  • Page 13: Sterilization & Maintenance

    STERILIZATION & MAINTENANCE: HANDPIECES - Thorough cleaning and Fig. 15 O-Rings lubrication of handpieces after each use and before sterilization is very important to ensure proper operation and service life of the handpiece. Follow the instructions provided with the handpiece for complete Fig.
  • Page 14: Sterilization & Maintenance

    STERILIZATION & MAINTENANCE - Cont'd 5. Push installer sleeve inward, until new O-ring MOTOR/CORD RECEPTACLE O-RINGS seats into groove on fitting (see Figure 18). The O-rings for the three water/air ports in the motor/cord receptacle should be replaced FIG. 18 if damaged or worn.
  • Page 15: Troubleshooting

    TROUBLESHOOTING: Problem: Correction: Console does not light up when on: • Check console to power connection. • Press Standby button on front panel. Console does not light up when on, • Unplug power connector from back of unit, wait 5 seconds, and chirping sound occurs: then reattach connector.
  • Page 16: Symbol Definitions

    SYMBOL DEFINITIONS: Attention, consult Dangerous Voltage accompanying documents Type BF Equipment Alternating current Class II Equipment Footswitch Do Not Throw In Trash Protective Earth (Ground) Temperature Limitation Manufacturer Authorized European Humidity Limitation Representative Atmospheric Pressure Limitation Motor Direction Light Controls Serial Number...
  • Page 17: Specifications

    SPECIFICATIONS: Environmental Conditions: Console Dimensions: 4.7”W x 6.8”L x 2.4”H - Operating Temperature 10 to 28°C (50 to 82.4°F) (11.9cm x 17.3cm x 6.1cm) - Transportation & Storage Temperature -20 to 60°C Console Weight: 1.38 lb (0.62 kg) (-4 to 140°F) OPERATING TRANSPORT &...
  • Page 18: Warranty

    Aseptico's sole obligation under product warranty is (at its sole option and discretion) to repair or replace any defective component or product in part or whole. Aseptico shall be the sole arbiter of such action.
  • Page 19 NOTES:...
  • Page 20: P.o. Box 1548 • Woodinville, Wa

    P.O. Box 1548 • Woodinville, WA 98072 8333 216 Street S.E. • Woodinville, WA 98072 (425) 487-3157 • (800) 426-5913 www.aseptico.com • info@aseptico.com P/N: 420819 Rev. E ECO 14684 PRINTED IN THE USA 03/2019...
