Powernail 2000TN Operation And Maintenance Manual

Pneumatic top nailer

Advertisement

Quick Links

POWERNAIL
Model 2000TN Pneumatic Top Nailer™
OPERATION AND MAINTENANCE MANUAL
MANUAL DE OPERACION Y DE MANTENIMIENTO
MANUEL D'INSTRUCTIONS ET D'ENTRETIEN
Read this manual before you use this Powernailer®. Follow all safety warnings and
instructions. If you are uncertain about the operation of the nailer, call us directly
at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help.
Please retain this information for future reference.
®
WARNING
CO.
REV 14.06.24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2000TN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Powernail 2000TN

  • Page 1 Read this manual before you use this Powernailer®. Follow all safety warnings and instructions. If you are uncertain about the operation of the nailer, call us directly at 1-800-323-1653 for assistance or contact the closest Powernail Dealer for help. Please retain this information for future reference.
  • Page 2: Table Of Contents

    INTRODUCTION The Model 2000TN trigger-pull top nailer is designed to bring Powernail quality and fl ooring expertise to a pneumatic nailer. The Model 2000TN is designed for use with 1” and 1-1/4”, 20 gauge L-Cleat Powernails ® . INDEX Index........
  • Page 3: Safety Instructions

    Nailer is intended for use installing wood fl ooring and is not to be used for purposes not specifi ed in the operations manual. Do not use any nails other than Powernail® Powercleats which are 20 gage L-cleat nails specifi cally designed for use in any 20 gage Powernailer. Powercleat nails are available in lengths of 1” and 1-1/4”. Contact your Powernail Dealer for the correct Powercleats for the Model 2000TN.
  • Page 4: Operating The Tool

    OPERATION To use the Model 2000TN, simply place the silver foot of the nailer against the fl ooring you wish to nail so that the safety mechanism is engaged. Gently squeeze the trigger and the nailer will drive and countersink the nail.
  • Page 5: Troubleshooting Chart

    TROUBLE SHOOTING CHART Here are some common issues that may occur during use. If the nailer is not working as it should, stop using the tool immediately and resolve the issue before continuing. PROBLEM POSSIBLE CAUSE SOLUTION 1. O-ring (31) in trigger valve is damaged. 1.
  • Page 6 OPERATION, continued... CONNECTING THE TOOL TO AN AIR SUPPLY Your air tool is fully assembled when you receive it. Before using it, attach the air line and desired air system accessories. Be sure the air hose is depressurized when installing or removing adapters to the air line.
  • Page 7: Air Supply

    MAINTENANCE 1. An automatic airline oilier is recommended but oil may be added manually before every operation or after about 1 hour of continuous use. 2. Place two (2) drops of air-tool oil in the air plug as shown (Figure 3). If you are using an automatic in-line oiler, check and add oil if necessary.
  • Page 8: Parts List

    MODEL 2000TN PARTS LIST Avail. Avail. ITEM DESCRIPTION PART # ITEM DESCRIPTION PART # SCREW M4 x 10mm TRIGGER PIN BUSHING SCREW M4 x 16mm EXHAUST COVER WASHER WASHER .125 DIA x .312 ROLL PIN 09-20FN2042 SCREW M5 x 20mm...
  • Page 9: Schematic

    MODEL 2000TN SCHEMATIC...
  • Page 10 CLEARING A JAM Disassembly: (See Figure 4.) 1) NOTE: Do not remove the two M5 screws (80). 2) Remove three M4 screws (78) with a 3mm allen wrench and lift off foot (71). 3) Slide the safety arm (75) to the side. 4) Lift the gate plate (72) off...
  • Page 11 Part number: 06-99650 Model 50P FLEX™ Model The Powernail Model 50P FLEX is truly a fl exible 50P FLEX nailer which can nail down the wide variety of fl ooring found in today’s market. Using the adjustable foot, you can fi...
  • Page 12: Phone Support

    POWERNAIL COMPANY, INC. 1300 Rose Road, Lake Zurich, IL 60047 US Phone: 1-800-323-1653 or 847-847-3000 www.powernail.com...
