Operation

5.1 Permanent magnet synchronous machine (PMSM)
– Configuration 806
5.1.1 Operation without encoder
5.1.1.1 Start
In order to prevent the machine from tilting, PMSM will always be started with current impression.
5.1.1.2 Isd current
For operation in the basic speed range, impression of a small positive Isd current (10% of rated cur-
rent) in the machine is recommended. Thus, current will be flowing, even in open-circuit state.
The SETUP will set Parameters
automatically to 10% of the rated current (Parameter 371).
In the case of PMSM, the value entered in Parameter
Parameter
No. Identifier
743
Ref. Isd Upper Limit
744
Ref. Isd lower limit
28
Ref. Isd Upper Limit
Unit
A
A
ACU
Spindle Applications
743 and
Ref. Isd Lower Limit
Isd Reference Value
Setting range
0,0 .. o·I
FIN
-o·I .. o·I
FIN FIN
744
743.
Default settings
o·I
FIN
0.0
