5.3.1

Identification of reference point position

When the frequency inverter is switched on during commissioning, the current position of the spindle
is identified by a search mode. The search mode continues for three revolutions at the set frequency
Reference Profile Frequency
positioned to the
Reference orientation
Parameter
No. Identifier
809
Reference Profile Frequency
If the motor has already turned before release of axle positioning, the frequency inverter knows the
position of the reference point. In this case, positioning is carried out based on the
469 without search mode.
tion
5.3.2 Definition of sense of rotation for axle positioning
Parameter
Operation Mode Homing
the homing operation after start of the inverter.
Parameter
No. Identifier
810
Operation Mode Homing
Operation Modes of Parameter 810
0 - Opt
1 - Clockwise
2 - Anticlockwise
11/13
809. As soon as the reference signal was recognized twice, the drive is
469.
Unit
Hz
810 defines the sense of rotation for positioning at standstill and
Unit
-
Optimized direction The direction of the homing op-
eration corresponds to the identified sense of rotation.
In the case of a standing machine, the positioning
operation starts with clockwise rotation.
Clockwise rotation. Homing and positioning will always
start with clockwise rotation in the case of a standing
machine.
Anticlockwise operation Homing and positioning will
always start with anticlockwise rotation in the case of
a standing machine.
ACU
Spindle Applications
Setting range
0.00 .. 50.00
Setting range
Selection
Default settings
1.00
Reference orienta-
Default settings
0 - Opt
37
