Operating characteristics

Parameter
Local Remote
contacts/control unit and/or the interface.
Parameter
No. Identifier
412
Local Remote
Operation Modes of Parameter 412
0 - Control via Contacts
1 - Control via Statemachine
2 - Control via Remote-Contacts
3 - Ctrl. KP, direction Contacts
4 - Ctrl. KP+Cont., direction Cont.
5 - Ctrl. 3-Wire, direction Cont.
13 - Control via KP, Direction KP
14 - Control KP+Cont., Direction KP
20 - Control Contacts, Clockw.
23 - Control Keypad, Clockw.
24 - Control Cont. + KP, Clockw.
30 - Control Contacts, Anticl.
33 - Control Keypad, Anticl.
34 - Control Cont. + KP, Anticl.
43 - Ctrl. KP, Dir. Cont. + KP
44 - Ctrl. Cont.+KP, Dir. Cont.+KP
46 - Ctrl. 3-Wire+KP, Dir. Cont.+KP
22
412 defines the operating characteristics and enables choosing control via
Unit
-
Commands Start and Stop as well as definition of
sense of rotation via digital signals.
Commands Start and Stop as well as definition of
sense of rotation via DRIVECOM statemachine of
communication interface.
Commands Start and Stop as well as definition of
sense of rotation via logic signals through the commu-
nication protocol
Commands Start and Stop from the control unit, defi-
nition of sense of rotation via digital signals.
Commands Start and Stop from the control unit or via
digital signals, definition of sense of rotation only via
digital signals.
3-wire; control of sense of rotation and the signal
Start 3-wire ctrl.
Commands Start and Stop as well as definition of
sense of rotation via control unit.
Commands Start and Stop via the control unit or digi-
tal signals, definition of sense of rotation only via con-
trol unit.
Commands Start and Stop via digital signals. Fixed
definition of sense of rotation: clockwise only.
Commands Start and Stop via control unit. Fixed defi-
nition of sense of rotation: clockwise only.
Commands Start and Stop via control unit or digital
signals. Fixed definition of sense of rotation: clockwise
only.
Commands Start and Stop via digital signals. Fixed
definition of sense of rotation, anticlockwise rotation
only.
Commands Start and Stop via control unit. Fixed defi-
nition of sense of rotation, anticlockwise rotation only.
Commands Start and Stop via control unit or digital
signals. Fixed definition of sense of rotation, anti-
clockwise rotation only.
Commands Start and Stop via control unit, Definition
of sense of rotation via control unit or digital signals.
Commands Start and Stop as well as definition of
sense of rotation via control unit or via digital signals.
3-wire and control unit. Control of sense of rotation
and signal
control unit.
ACU
Spindle Applications
Setting range
44 - Ctrl. Cont.+KP,
Selection
87 via digital signals.
87 via digital signals or
Start 3-Wire Ctrl
