Maxxus RunMaxx 6.3 Installation & Operating Manual page 8

Assembly
Step 7 - Inserting the Safety Key
Insert the safety key in the cockpit (B). Cut and remove the transport strap (P).
B
D07
P
Step 8 - Remove the second transport lock
Loosen and remove the hexagon socket screw M8x15 (E13) with the steel cable (E) on the main frame (Located
as shown).
Now fold up the treadmill. Then loosen and remove the Allen bolt M8x15 (E13) with the steel cable (E) attached
to the inside of the main frame.
Note: Keep the steel cable (E) and the two screws (E13). You can use them if you want to disassemble the
treadmill for transportation or to save some space.
Illustration 1
E
E13
E
E13
Illustration 1
Step 9 - Check the lubrication of the running belt
The running belt has been lubricated at the factory but there is a possibility that due to delivery, storage time
and weather conditions (warm season) the lubrication is partly to completely dried out. For this reason, check
whether the running belt is sufficiently lubricated and lubricate if necessary. Please read the chapter "Lubrication
of the running belt" in this manual.
Lubrication region
Illustration shows similar treadmill
8
