- Page 1 MAXXUS 6.1 Rowing Machine...
- Page 2 Maxxus Group GmbH & Co. KG. Duplication, including electronic form, is only permitted with prior written permission directly from MAXXUS Group GmbH & Co. KG. Errors, colour and technical modification are subject to change...
-
Page 3: Safety Instructions
Safety Instructions Please read and observe all sections of this Operating Manual before you start with training. Thorough attention should be paid to the safety, cleaning and maintenance instructions and the training informa- tion. Please also make sure that anyone using this device is familiar with all this information. It is very important to adhere strictly to the safety and maintenance instructions contained in this Manual. -
Page 4: Overview Of The Device
Overview of the Device 10 level resistance adjustment Cockpit Rowing handle Pedal Seat Sliding Rail Stabilizer Folding Mechanism Stabilizer... - Page 5 Fixing Material Part Desrcription Rear Decoration Seat Carriage Stopper, Iron Bush Knob Washer M8 Cap Nut M10 Nylon Nut M10 Washer M10 Spring Washer M8 Allen Head Bolt M10x20 Allen Head Bolt M8x25 Allen Head Bolt M10x25 Spring Washer M10 Allen Head Bolt M8x15 Nut M8 Allen Head Bolt M8x85...
-
Page 6: Scope Of Delivery
Scope of Delivery U Bracket Part 2 Main Rowing Rail Part 4 Main Frame Part 1 Seat Part 13 Rear Stabilizer Front Stabilizer Slide Joining Part 5 Part 6 Part 8 Pedal, left Pedal, right Cockpit Cockpit Holder Part 12L Part 12R Part 84 Part 150... - Page 7 Assembly Assemble the parts carefully as any damages or defects occurring due to mistakes made at the time of assembly are not covered by the warranty or guarantee. Therefore, read through the assembly instructions carefully before you start assembling, follow each assembly step exactly as described and keep to the correct sequence of assembly as instructed.
- Page 8 Assembly Step 2: Assembly of the Seat From the rear, slide the joining (8) pre-assembled to the underside of the seat (13) onto the main rowing rail (4). Make certain that the seat (13) is facing the right way. Then fix the one seat carriage stopper (22) to the rear left and right sides the main rowing rail (4).
- Page 9 Assembly Step 4: Assembly of the Pedals Fix the right pedal (12R) to the right side of the main frame using three Allen head bolts (111), three flat washers M10 (77) three spring washers M10 (114) and three nylon nuts M10 (76). Repeat this procedure to assemble the left pedal (12L).
- Page 10 Assembly Step 5: Assembly of the Main Rowing Rail Connect the monitor cable (130) protruding out of the front end of the main rowing rail (4) with the monitor cable (129) coming out of the main frame (1). Now fit the main rowing rail (4) into the main frame (1) and fix it right and left with an Allen head bolt M8x25 (110) and a spring washer M8 (26) on each side.
- Page 11 Assembly Step 6: Assembly of the Cockpit Holder and Cockpit Loosen and remove the two countersunk screws M5x20 (151) and the four round head screws M5x20 (152) on the back of the cockpit (84). Feed the cockpit cable from the front through the square opening in the cockpit holder (150) – see Fig.
- Page 12 Folding Mechanism Folding up the Main Rowing Rail Step 1: Push the seat completely forward and fold back the cockpit frame. Step 2: Loosen knob (24) enough so you can pull it down and fold up the main rowing rail (4). Step 3: Secure the main rowing rail with the pin (109).
- Page 13 Cockpit Position To optimise readability of the cockpit on the rowing machine, or to adjust it according to user height, the cockpit arm is infinitely adjustable and allows the cockpit to be positioned to suit easily per hand. Adjustment of the Resistance Alongside the natural resistance it is also possible to make additional adjustments to the resistance in 10 different levels.
-
Page 14: Care, Cleaning & Maintenance
Care, Cleaning & Maintenance CAUTION: Before you perform any care, cleaning, maintenance, repair or similar work on your training device, turn off your exerciser and remove the power cord. Check before starting the planned work that your exerciser is completely disconnected and switched off. Only when all work is fully completed, and the device is completely re-assembled, may the training device to be reconnected to the mains and turned on. - Page 15 Cockpit Distance Shows the current training distance from 0 ~ 999 km. Rowing Strokes Per Minute (SPM) Shows the current speed in rowing strokes per minute. This value is updated permanently. Total Rowing Strokes (Counter) Shows the number of rowing strokes for the current training session from 0 ~ 9.000. Speed Shows the current speed from 0.00 bis 99.9 km/h.
-
Page 16: Training Instructions
Training Instructions In the following you will find instructions and tips to help you to do the rowing movements correctly. Rowing Motion – complete body Step 1: Preparation Make sure that your feet are in positioned correctly on the pedals and that they are adjusted correct- ly to fit your shoe size with the straps firmly around your feet. -
Page 17: Training Recommendations
Training Recommendations Preparation Before Training Before you start training make sure that not only your training device is in perfect condition, your body must also be prepared for training. Therefore, if you have not done any endurance training for some time, you should con- sult your GP and undergo a fitness check-up. - Page 18 Training Recommendations Hydration Adequate hydration is essential before and during exercise. During a training session of 30 minutes it is possible to lose up to 1 litre of liquid. To compensate for this fluid loss apple spritzer mixed in the ratio of one-third apple juice to two-thirds mineral water is ideal since it contains electrolytes and minerals to replace those that the body loses through sweat.
- Page 19 In addition to the air resistance braking system which creates construction and the air flow noises when in use, noises also occur from the chain pulley. Your MAXXUS® training device is fitted with extremely high-quality components which ensure that all operating, air flow and chain noises are greatly reduced.
-
Page 20: Recommended Accessories
MAXXUS® Special Foam Cleaner – Use for regular cleaning of your training device. Plastic covers and metal frames can be easily cleaned and perfectly maintained with MAXXUS ® Special Foam Cleaner. It is also suitable for cleaning pulse belts and other training accessories. -
Page 21: Technical Details
Technical Details Cockpit Display of: − Time − Rowing Strokes per Minute − Distance − Speed − Calorie Consumption − Total Rowing Strokes Technical Details: Resistance System: Air resistance Pulley System: Chain pulley with egonomically formed rowing handle Dimensions: approximately 2,250 x 580 x 990 mm (LxWxH) Dimensions, folded: approximately 1,200 x 580 x 1,490 mm (LxWxH) Total Weight:... -
Page 22: Exploded Drawing
Exploded Drawing 96 145 133R 133L 125 148 10 78 77 152... - Page 23 Exploded Drawing...
-
Page 24: Parts List
Parts List Part No. Description Part No. Description main frame allen head bolt M8x35 U bracket chain pulley joining plastic tube main rowing rail flat washer rear stabilizer clip front stabilizer Iron bush foot plate bracket elastic cord xing wheel slide joining monitor bracket chord Ubracket... - Page 25 Parts List Part No. Description Part No. Description flat washer M10 rear joining bracket plastic spacer lock cap nut hexhead bolt M10x130 allen head bolt M8X15 hexhead bolt M10x70 spring round head screw M5x12 sensor bracket air flow adjuster sensor bracket round head screw M5x15 rowing rail bracket monitor...
-
Page 26: Terms And Conditions Of Warranty
The warranty period for your training device starts on the date of purchase and applies solely to products which were purchased directly from the MAXXUS Group GmbH & Co KG or one of the MAXXUS Group GmbH & Co KG direct and authorised distribution partners. -
Page 27: Device Details
I accept the General Terms and Conditions of MAXXUS® Group GmbH & Co. KG. I hereby instruct the company MAXXUS® Group GmbH & Co. KG to repair the above defects. In Warranty cases I will not be charged for the cost. The costs for repairs which are excluded from liability for defects in quality will be charged to me and must be settled immediately. - Page 28 Maxxus Group GmbH & Co. KG Zeppelinstr. 2 D-64331 Weiterstadt Germany E-Mail: info@maxxus.de www.maxxus.de...
