Interface description
6.4 PLC I/O Interface based on PROFINET
6.4.1

Addressing the I/O modules

IP addresses of the I/O modules
You can find the DIP switch S1 for the IP address of the appropriate I/O module in the
following table. In this case, the maximum configuration with I/O modules, bus coupler and
machine control panel via the PLC I/O Interface based on PROFINET is taken into
consideration.
I/O module
1st digital PP module
2nd digital PP module
3rd digital PP module
4th PP module digital
5th digital PP module
Unassigned
1st PP module diagnostics
2nd PP module diagnostics
3rd PP module diagnostics
4th PP module diagnostics
5th PP module diagnostics
1st analog PP module
2nd analog PP module
3rd analog PP module
4th analog PP module
5th analog PP module
PN/PN coupler *
External machine control panel
Reserved
Sentron PAC 4200 *
Sentron PAC 3200 *
The Index n, m, d is always the start address of the address range.
*) The IP address of these components is not set using a switch but rather configured appropriately.
80
Bus Device name
PN pp72x48pn9
PN pp72x48pn8
PN pp72x48pn7
PN pp72x48pn6
PN pp72x48pn5
PN pp72x48pn9
PN pp72x48pn8
PN pp72x48pn7
PN pp72x48pn6
PN pp72x48pn5
PN pp72x48pn9
PN pp72x48pn8
PN pp72x48pn7
PN pp72x48pn6
PN pp72x48pn5
PN pn-pn-coupler20
PN mcp-pn64
--
PN pac4200-pn21
PN pac3200-pn22
IP address Input addresses
192.168.214. (active with MD12986[x] = -1)
Index n:
9
8
7
6
5
Index d:
9
8
7
6
5
Index m:
9
8
7
6
5
20 96 ... 111
64 112 ... 125
-- 126 ... 131
21 132 ... 143
22 144 ... 155
Manual, 03/2013, 6FC5397-2DP40-3BA1
Output addresses
0 ... 8 0 ... 5
9 ... 17 6 ... 11
18 ... 26 12 ... 17
27... 35 18 ... 23
36 ... 44 24 ... 29
45 30 ... 55
46 ... 47
48 ... 49
50 ... 51
52 ... 53
54 ... 55
56 ... 63 56 ... 63
64 ... 71 64 ... 71
72 ... 79 72 ... 79
80 ... 87 80 ... 87
88 ... 95 88 ... 95
96 ... 111
112 ... 121
122 ... 123
132 ... 143
144 ... 155
--
--
--
--
--
PPU
