Shutdown Mode
Inverters automatically stop running during periods of little or no sunlight. In shutdown mode the inverters take no
power from the grid and panel, and the LCD and LED turns off.
Notes: If the PV string DC voltage is too low, the inverter will also turn to Shutdown Mode.
Derating mode
When AC frequency is higher than 50.3Hz(settable), the inverter will derate its output power according to the rule.
When user set the output power limit command to the inverter, the inverter will also limit the output according to
the setting.
In this derating mode, the LCD will show "DERATING".

6.3 Initial Settings and LCD Display

In the lower right corner of inverter there is the LCD display. We can check inverter running state, historical
generation data, etc, on the LCD screen. Items displayed can be changed by knock; you can also change some
inverter parameters by knock.

6.3.1 Initial Settings

If it is the first time the inverter starts up after installation, LCD will quickly switch to and stay at the grid code
setting interface that is the first setting interface of initial settings. Only the inverter is completed all initial settings,
it will work and display normally. Otherwise, LCD will always stay at the 'Please select' interface.
Grid code (Country) setting
Please finish the grid code setting according to the following steps:
1) When at the first interface 'Please Set Cert:' the option is 'VFR2014' in default. By single knock, grid
codes will vary from one to another, for example, 'VDE0126-1-1/A1', as Fig 6.3.1 and Fig 6.3.2
Note: If you have ordered the inverter with specific grid code settings, the parameters have been preset
in factory and you don't need to operate this step any more.
2) There are five grid codes to select:
Note: if you can't find the grid code you want, please contact CyberPower Systems, Inc.
3) When it comes to the grid code you want, double knock to enter, as Fig 6.3.3.
User Manual
Please set Cert:
VFR2014
Fig 6.3.1
1
2
3
4
5
6
Please set Cert:
VDE0126_1_1/A1
Fig 6.3.2
VDE0126-1-1
VDE0126-1-1/A1
VDE0126 Taiwan
PEA Thailand
VFR 2014
IEC61727+62116
