OPERATION and MAINTENANCE
INSTRUCTION MANUAL
AMC-20 Mobile Dental System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMC-20 and is the answer not in the manual?

Questions and answers

Related Manuals for Aseptico AMC-20

Summary of Contents for Aseptico AMC-20

  • Page 1 OPERATION and MAINTENANCE INSTRUCTION MANUAL AMC-20 Mobile Dental System...

  • Page 2: Table Of Contents

    The AMC-20 is a mobile self-contained dental system that is However, high levels of radio-frequency (RF) emissions from electrical devices, such as cellular phones, may disrupt the used for endodontic and general dentistry applications.

  • Page 3: Introduction

    Congratulations Your new Aseptico AMC-20 Dental System is the finest mobile dental system available. The System provides an array of standard and optional dental equipment features and functions designed to serve a wide range of dental applications -- all conveniently packaged into a single self-contained transportable cart.

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS: Aseptico accepts no liability for direct or consequential injury or damage resulting from improper use, arising in particular through the non-observance of the operating instructions, or improper preparation and maintenance. WARNING: Clean, disinfect, and sterilize new or repaired handpieces and instruments before first use and between each patient use.

  • Page 5: Setting Up The Unit

    SETTING UP THE UNIT: 5. Fill the water FIG. 4 bottles with clean 1. Unpack the AMC-20 WATER FIG. 1 BOTTLE CAPS water or other Dental System from suitable irrigation its cardboard crate fluid and attach to (Fig. 1) See page 19.
  • Page 6 (Fig. 7) per the instructions provided on page waste compartment door 20 or in the on the back side of the Aseptico unit and place the "Packing Guide", optional amalgam included in the case. separator into the 10. Attach the optional AEU-5000 Electric amalgam manifold.
  • Page 7 OPTIONAL OPTIONAL (COOLANT VALVE FIG. 12 - AMC-20 w/Options (Front View) OPTIONAL OPTIONAL FOR 3RD AIR SCALER BOTTLE COOLANT HANDPC OPTIONAL OPTIONAL SELECTOR COOLANT FLUSH ACCESSORY TRAY TOGGLE TOGGLE VALVE TOGGLE ELECTRIC HAND- HINGED LID PIECE) ALLOWS ACCESS TO PLUMBING SYRINGE, HIGH &...
  • Page 8 SETTING UP THE UNIT- Cont’d FIG. 13 - AMC-20 w/Options (Back View) OPTIONAL OPTIONAL ACCESSORY TRAY w/ADJUSTABLE HOLDER WASTE HOSE w/HANGER OPTIONAL OPTIONAL 10 AMP 20 AMP CIRCUIT CIRCUIT BREAKERS (2) BREAKERS (2) FOR 220V WASTE COMPARTMENT LATCH 1 AMP...
  • Page 9 FIG. 14 - AMC-20 w/Options (Back View) WASTE CONTAINER OPTIONAL OPTIONAL AMALGAM SEPARATOR FILTER REGULATOR OPTIONAL PRESSURE OPTIONAL OPTIONAL OPTIONAL REGULATOR AMALGAM WASTE FLOW FIBER OPTIC SEPARATOR CURING LIGHT MODULE VALVE RETAINING OPTIONAL SCREW OPTIONAL OPTIONAL SCALER AMALGAM SHIPPING BYPASS...

  • Page 10: Operation Functions

    15). HANDPIECE FIG. 18 HIGH VACUUM 2. INSTRUMENT CONTROLS (Figs. 16 & 17) (HVE) SALIVA The Aseptico AMC-20 includes controls for SYRINGE EJECTOR all handpiece and instrument holders. Each holder includes an FIG. 16 On/Off toggle switch (see Fig. 16) which when...
  • Page 11 FIG. 20 COOLANT FOR BOTTLE SELECTOR TOGGLE FLUSH TOGGLE COOLANT AIR TOGGLE AIR HANDPCS #1 & #2 COOLANT FOR AIR HANDPC #3 OPTIONAL OPTIONAL COOLANT AIR CONTROL VALVE BOTTLE PRESSURE SCALER RELEASE TOGGLE OPTIONAL OPTIONAL ELECTRIC HANDPC COOLANT different solutions (NOTE: The yellow and about 5 seconds after every patient, and blue floating level indicators can be used about 20 seconds at the beginning of each...

  • Page 12: Optional Equipment Functions

    OPERATION FUNCTIONS - Cont'd: 12. WASTE PUMP SWITCH & WASTE DISCHARGE OPTIONAL EQUIPMENT FUNCTIONS: QUICK DISCONNECT (Fig. 21) – A waste pump 15. OPTIONAL AEU-5000 ELECTRIC switch is provided on the back of the unit to purge MOTOR & CONTROL PANEL (Fig. 22) - the waste system.
  • Page 13 Fig. 22 - Optional Electric Motor Control Panel PRESET SELECTOR HANDPIECE RATIO w/DISPLAY SELECTOR w/DISPLAY CONTROL PANEL MOTOR DIRECTION STANDBY (FWD/REV) SELECTOR BUTTON w/DISPLAY ENDODONTIC MODE SPEED (RPM) (ENDO) SELECTOR SELECTOR w/DISPLAY w/DISPLAY TORQUE ILLUMINATION SELECTOR ADJUSTMENT w/DISPLAY w/DISPLAY button repeatedly until the word "ENDO" Fig.
  • Page 14 OPTIONAL EQUIPMENT FUNCTIONS - Cont’d: the Preset button to toggle the ratio to either as the adjustments are made. The display enabled or disabled status. The word "On" will icon will blink as the adjustments are made. To exit the adjustment mode, press appear in the Preset display window when enabled, and two dashes "_ _"...
  • Page 15 The last used overwritten. settings will be restored. SLEEP MODE: After 20 minutes of motor 16. OPTIONAL SCALER (Fig. 26, page 14) – inactivity, the optional Electric Motor Module The AMC-20 offers an optional piezo- automatically enables an energy-saving...
  • Page 16 FIG. 27 PIVOT DOCUMENTS BLOCK 17. OPTIONAL CURING LIGHT (Fig. 17, page 8) - The AMC-20 offers an optional LED curing light. When the light is removed from the holder and the foot pedal is depressed, the light turns On. Releasing...

  • Page 17: Routine Adjustments

    1-liter per minute flow counterclockwise will increase the pressure. setting for the specific amalgam separator provided with this AMC-20 Cart. An optional FIG. 28 bypass filter is available for areas where WATER FLOW amalgam separators are not required.

  • Page 18: Sterilization & Maintenance

    The trap sits inside the central vacuum canister located under the top lid. Keep spare traps in stock. The AMC-20 uses standard 1 7/8” traps (open or closed type): To insert a new tip, press locking collar and push tip into socket as far as it will go. Release ring and gently tug on tip before using to ensure that tip is securely locked into socket.
  • Page 19 PTFE) to O-rings to maintain flexibility. tank discharge. Replacement amalgam separators (PN 730595) are available through Aseptico. Refer to the label on the amalgam separator for the address of an approved amalgam recycler.

  • Page 20: Sterilization & Maintenance

    OPTIONAL EQUIPMENT STERILIZATION AND MAINTENANCE - Cont'd: OPTIONAL MOTOR LED LENS CLEANING: minimum. Clean and sterilize probe between The lens of the LED light on the optional electric each patient use. NOTE: The lamp module motor (Fig. 33) is soft and can be damaged. It (the section that seats into the tubing should not be exposed to dust and debris.

  • Page 21: Packing/Unpacking Instructions

    FIG. 43 strapping blocks onto the edges of STRAP the Lid as shown (X4) in Figure 43, then connect the straps overtop the blocks and tighten. NOTE: To unpack the AMC-20 unit, perform the above repacking steps in reverse order.

  • Page 22: Optional Case Packing Instructions

    10. Secure and tighten the holding straps on the loading ramp. sides of Cart. Wrap the straps once around 6. Carefully roll the AMC-20 unit, back side first, the side handles. up the ramp and into the case. Use the two 11.

  • Page 23: Troubleshooting

    TROUBLESHOOTING: Problem: Correction: Unit will not start: • Check system power connection. • Check voltage selector switch for proper voltage. • Check circuit breakers. • Check if waste tank sensor is connected. • Check if waste tank is full. Unit starts but trips circuit •...

  • Page 24: Specifications

    67.8 fl. oz. (2.0 liters) IMPORTANT Air Storage Capacity: 1.93 gal.(7.3 liters) nominal Air Storage Pressure: 110 PSI (7.58 bar) When running the AMC-20 unit at 50Hz, expect approximately Water Flow: 5.07 fl. oz./min (0.15 liter/min) 17% less vacuum and pres- Waste Tank Capacity: 1.08 gal.

  • Page 25: Symbol Definitions

    SYMBOL DEFINITIONS: Type B Equipment Protective earth (ground) IPX1 Protect Against Dripping Water Type BF Equipment Attention, consult Serial Number accompanying documents Dangerous Voltage Footswitch On/Off Switch - Auxillary Alternating current Authorized European On/Off Switch - Mains Representative Bottle Pressure Release Toggle Manufacturer Bottle Select Toggle Air Coolant Control...

  • Page 26: Replacement Parts List

    BOTTLE 1000ml ZIRC KIT 730631-01 LINECORD US HOSPITAL GREY 15A/125V 10 FT 840101 LINECORD EURO BLACK 15A/250V 2.5 M 840102 AUXILIARY ARM MOBILE DENTAL CART AMC-20 AA-20A CANISTER CENTRAL VACUUM GRAY AA-290 AMALGAM SOLIDS TRAP - OPEN TYPE AA-29 AMALGAM SOLIDS TRAP - OPEN TYPE...

  • Page 27: Warranty

    WARRANTY Aseptico warrants its products against defects in material or workmanship for a period of two (2) years, from date of original invoice. Some handpieces are warranted for one year under the same conditions. Other handpieces and expendable components, such as air turbines and light bulbs, are covered by shorter warranty periods, or have no warranty.

  • Page 28: P.o. Box 1548 • Woodinville, Wa

    P.O. Box 1548 • Woodinville, WA 98072 8333 216th Street SE • Woodinville, WA 98072 (425) 487-3157 • (800) 426-5913 www.aseptico.com • info@aseptico.com P/N: 420869 Rev. M ECO 14212 PRINTED IN 06/2017 THE U.S.A.
