  • Page 1 ALU-40LED-CF Portable Dental Lamp NSN: 6520-01-600-8241 OPERATION & MAINTENANCE MANUAL...
  • Page 2: Table Of Contents

    CERTIFIED TO CSA STD C22.2 NO. 601.1 INFORMATION CONCERNING THE ACCURACY AND PRECISION OF THIS PRODUCT MAY BE OBTAINED UPON REQUEST BY CONTACTING ASEPTICO AT THE ADDRESS SHOWN ON THIS PAGE. To prevent injury to people and damage to property, please heed relevant warnings and remarks.
  • Page 3: Introduction

    Your new Aseptico ALU-40LED-CF Lamp is one of the finest operating lights available to the dental and medical professions. The ALU-40LED-CF uses an LED light source which provides brilliant white light, reduced power consumption, and longer operating life. The universal voltage input Lamp operates from 100VAC to 240VAC, 50 and 60Hz, and it provides an auxillary DC input that allows 12V and 24V battery operation in the field.
  • Page 4: Safety Precautions

    All repairs to the LED Assembly, Boom Arm, and Power Supply are to be performed by authorized Aseptico service personnel only. WARNING: Do not install where there is a risk of an explosion. The ALU-40LED-CF is not intended for operation in the presence of flammable anesthetics or gases. CAUTION: Connect AC power supply mains cable to a properly grounded outlet only.
  • Page 5: Setup

    COMPARTMENT ADJUSMENT KNOB PEDESTAL FOLDING LEGS Remove the ALU-40LED-CF Lamp from Loosen the handgrip on the center post its carrying case. Unfold the tripod legs to (see Figure 1) and raise the post to the a horizontal position. Loosen the desired height.
  • Page 6 Figure 2, page 3) and plug cord into a DC BATTERY CLIP grounded electrical outlet. NOTE: The ASSEMBLY ALU-40LED-CF Lamp features auto- sensing, global voltage compatibility for 100VAC, 115VAC, 230VAC, and 240VAC at 50Hz and 60Hz. The fuses provided are correct for these line voltages. NOTE: A USA style 125V power cord and Euro style 220V cord are shipped with the unit.
  • Page 7: Operation

    OPERATION: After the ALU-40LED-CF Lamp has been set Fig. 4 - Illumination Controls up, the unit is ready to operate: Ensure that the protective Lens Cover is BRIGHTER BEAM mounted onto the front of the Lamp Head WIDER BEAM (see Figure 4).
  • Page 8: Maintenance

    Lens so that it emits the sharpest Assembly are not field serviceable and beam (refer to Figures 6 & 7): must be returned to Aseptico if repairs are a) Position Lamp Head approximately required. 28" (71 cm) away from a flat test FRESNEL LENS REPLACEMENT: surface.
  • Page 9 ALU-40LED-CF Lamp. component of the inside of the Lamp Head Housing Return the entire Lamp Assembly to or the Power Supply Assembly. Aseptico if LED repairs are necessary CLEANING: FUSE REPLACEMENT: a) Fresnel Lens: WARNING Remove Lens Cover and Fresnel Lens from Lamp Head.
  • Page 10 ALU-40LED-CF PARTS DIAGRAM Figure 9 - Lamp Stand Boom ALU-40LED-CF LAMP HEAD: Refer to Figure 11, page 12...
  • Page 11 HOLE PLUG NYLON 1/2 IN BLACK 510202 M/S STNLS PHDPHL 10-24 X 5/8 THRD CUTTING 510732 END CAP, MODIFIED BOOM, ALU-40 461959 CABLE COILED 2 CONDUCTOR ALU-40LED-CF 870319 HANDLE CLAMP LEVR, M8X1.0 FEM THRD, BLK 850076 CLAMP, BOOM ALU-40 LED 730646...
  • Page 12 ALU-40LED-CF PARTS DIAGRAM Figure 10 - Lamp Stand & Power Supply...
  • Page 13 PARTS LIST - Lamp Stand & Power Supply Item Description Part Number BRACKET POLE POWER SUPPLY ALU-40LED-CF 461945 C/S BTNSOC BLK 6-32 X 1/4 510009 OVERLAY POWER SUPPLY ALU-40LED-CF 420911 TOP HOUSING POWER SUPPLY ALU-40LED-CF 461943 TIE WRAP 4" PICO WHT...
  • Page 15 RES 100K TRIM POT 350V 1/2W 810430 WIRE #24 TEFLON 41/40 TINNED COPPER WHT 870314 WIRE #24 TEFLON 41/40 TINNED COPPER BLK 870320 PCB ASSY LAMP HEAD ALU-40LED-CF 330578 FTN UNIVERSAL JOINT M10-1.0 MALE THRDS 730643 WASHER #6 NYL .140 ID X .312 OD X .032 THK...
  • Page 16: Troubleshooting

    Lamp ‘Off’.) - Check plug and electrical source. - LED Assembly might be damaged - Return entire Lamp Assembly to Aseptico for repairs. - Replace both fuses, 0.160 Amp, 5 x 20mm, 250V, Fuse is blown:...
  • Page 17: Specifications

    SPECIFICATIONS: Environmental Conditions Lamp Height: 41" to 69" (Adjustable) (104.1 cm to 175.3 cm) Operating Temperature: 10 to 45°C (50 to 113°F) Transportation & Storage Temperature:-20 to 60°C Boom Length: 41" (104.1 cm) (-4 to 140°F) Weight: 9.45 lbs (4.29 kg) Relative Humidity: 10 to 90% non-condensing AC Input: 100-240V...
  • Page 18: Symbol Definitions

    SYMBOL DEFINITIONS: Attention, consult Protective Earth (Ground) accompanying documents Type B Equipment Temperature Limitation Class II Equipment Humidity Limitation Dangerous Voltage Atmospheric Pressure Limitation Alternating current Do Not Throw Into Trash Manufacturer Fuse Rating 0 160A Authorized European Representative...
  • Page 19: Warranty

    Aseptico's sole obligation under product warranty is (at its sole option and discretion) to repair or replace any defective component or product in part or whole. Aseptico shall be the sole arbiter of such action.
  • Page 20 P.O. Box 1548 • Woodinville, WA 98072 8333 216 Street S.E. • Woodinville, WA 98072 (425) 487-3157 • (800) 426-5913 www.aseptico.com • info@aseptico.com P/N: 420914 Rev. G ECO 14684 PRINTED IN THE USA 03/2019...
