Alarms and Troubleshooting

For all alarms conditions, the troubleshooting steps provided in this chapter are suggested
actions to take in the event of an alarm. Follow all site policy procedures set by local governing
agencies in the case of a spill, leak, or malfunction. If the steps provided by this manual or
the site policy are followed and the system still requires additional support, contact Franklin
Fueling Systems Technical Services. Alarms are listed in sections for System Alarms, VRM Alarms,
FMS Alarms, SCM Alarms, Wire Sensor Alarms, LLD Alarms, TPI Alarms, Printer Alarms and
Miscellaneous Alarms.

System alarms

Displayed
Device
Alarm/Warning
Invalid None
Configuration
Invalid Registration None
Power Supply Input None
Alarm
Printer Module Slot
Number Mismatch
Probe Setup Error None
Set Date and Time None
System Setup Error None
Description
The configuration that has
been loaded is not valid.
The registration that is
loaded is not valid.
An input on the Power Supply
has been configured as an
alarm and is active.
Printer Modules detected
does not match the number
programmed.
Programming errors made
during setup of the Probe
Module.
System detected an issue
with the date and time
There is an error in the Setup
configuration.
Recommended Actions
Verify the file type of the configuration which is
being uploaded
If you have upgraded the site before, use the
upgrade tool to restore the former registration.
If you have not upgraded the site before, contact
FFS Technical Services for support.
Check the programming and voltage inputs for the
specified Low Voltage Input channel on the Power
Supply module.
Check that the number of Printer Modules
installed matches the number programmed under
System Configuration > Modules Expected. If
problem persists, contact FFS Technical Support.
Verify Probe Module programming parameters. If
the condition still exists, contact Franklin Fueling
Systems' Technical Support for help on this issue.
Check and set the system date and time.
Inspect the System setup configuration for
possible errors.
