Web Browser Interface

Navigating Applications Remotely

The Web Browser Interface offers several ways to navigate through applications:
• Easy-to-read web pages that use hyperlink text (words or characters that, when clicked, take
you to another page) to move through the menus.
• Text and drop boxes and buttons allow inputs to be made efficiently,
• On-screen prompts automatically pop-up instructions to verify each step.
Not all application functions, like Network Configurations, are available at all levels. To access
these options, you need to be logged in at a high enough User Role.

Accessing the Web Browser Interface

IMPORTANT: Enter "https://" before you enter an IP address.
1. To access the console using a computer, open a web browsing application.
2. Type the IP address (default is "https://192.168.168.168") into the address bar of the
browser window. To access the console using a remote PC, setup communications per
Section 2 of this manual. When using a PC to access console applications through a direct
or network connection, the EVO™ 200 or EVO™ 400 ATG incorporates a XML (eXtensible
Markup Language) based access method. If the console is equipped with an optional LCD
screen, the connection settings may be modified using the touch screen function of the
console.

Making Changes to System Parameters

1. Go to: Settings>Configuration.
2. To make any changes on a settings page, click the appropriate menu section and edit the
section as needed.
3. Once the preferred selections have been altered, click the confirmation option Save in the
upper right hand corner.
4. You must have administrative access to make setup changes.
