    Introduction This manual contains installation instructions for the Franklin Fueling Systems (FFS) 200 and EVO 400 Automatic Tank Gauges (ATGs). You must follow all safety information, warnings, instructions, and other information in this manual. Please read this entire manual carefully. If you do not follow the instructions in this manual, the result could be faulty operation, equipment damage, injury, or death.
  • Page 6: Operating Precautions

    Operating precautions FFS equipment is designed to be installed in areas where volatile liquids such as gasoline and diesel fuel are present. Working in such a hazardous environment presents a risk of severe injury or death if you do not follow standard industry practices and the instructions in this manual. Before you work with or install the equipment covered in this manual, or any related equipment, read this entire manual, particularly the following precautions: IMPORTANT: To help prevent spillage from an underground storage tank, make sure the delivery...
  • Page 7: Programming And Operation Documentation

    Programming and operation documentation The EVO 200 and EVO 400 Automatic Tank Gauges Operation Guide and the EVO 200 and 400 Automatic Tank Gauges Programming Guide are useful manuals you may need. To download these manuals, go to: www.franklinfueling.com>Products>Fuel Management Systems>Automatic Tank Gauges>EVO 200 &...
  • Page 8: Specifications

    • Perform tank reconciliation and autocalibration. • Print reports on an external USB printer. • You can access remotely via Ethernet or RS-232 with a web browser. • Perform leak detection and density monitoring. Specifications The specifications for an EVO 200 or EVO 400 ATG are: •...
  • Page 9: Console Installation

    Console Installation Console location Install the console indoors in an area that has a pollution degree 2 rating and is classified as non- hazardous (per IEC60664). Place the console at eye level, for convenience, on a level, vertical surface 2–6' (0.6–1.9 m) high. Use appropriate fasteners. Mounting the console Removing the cover WARNING: Mount the console in a location where explosive or flammable vapors are...
  • Page 10: Standard Installation Materials

    Standard installation materials Select and install standard installation materials according to local, state, and federal codes that govern the installation of this product and its associated systems. See the console, module wiring, or associated devices section of this manual for details. Circuit breaker The console has a 20 Amp circuit breaker that provides power for only the console.
  • Page 11: Riser Pipes

    Riser pipes ANSI Schedule 40- (or chemically non-reactive) 2 or 4 inch (50.8 or 101.6 mm) (8 NPT) riser pipes for liquid level probes. Cables required for liquid level probes and 4-20 mA sensors Use cables and wires compliant with national and local codes. FFS recommends using the types of cable shown below up to a recommended length of: •...
  • Page 12: Console Dimensions

    Console dimensions Power LED Warning LED Alarm LED Non-IS wiring compartment IS wiring compartment...
  • Page 13: Wiring The Console

    Wiring the console Intrinsically safe wiring Intrinsically safe outputs IMPORTANT: Do not run IS and non-IS wiring in the same conduit. IMPORTANT: If local codes do not require you to use conduit, you must use cable glands at all enclosure knock-outs. Gaps larger than 0.06" (1.5 mm) violate safety approvals. Make sure you provide adequate IS and non-IS wire separation.
  • Page 14: Udp Probe And Sensor Wiring

    UDP probe and sensor wiring The probe and sensor wiring is IS and is kept separate from all other wiring. Conduit must enter the console enclosure through only the designated knockouts. The installation may require the conduit to enter on top or bottom. Do not lose the conduit plugs, and make sure any openings are covered by the plugs.
  • Page 15: Line Power Wiring

    Cables required for liquid level probes Use cables and wires compliant with national and local codes to help provide reliable communication between the console and probes. FFS recommends using the types of cable shown in the table below. Cables must be oil and water resistant, 22 AWG (or greater), and must be shielded, twisted pairs.
  • Page 16: Check Electrical Resistance To Earth Ground

    Check electrical resistance to earth ground After wiring the IS safety grounds, check the resistance between the IS safety ground terminals at the console and the earth ground. This resistance must be less than 1 ohm. 110/240 VAC line power wire connections Electrical Panel No.
  • Page 17: Rs-232 Communication Connectors

    Port Connector Type Devices 1 RS-485 Pluggable terminal block TPI/FE Petro Smart Controllers 2 Micro-USB Female micro-USB Local network or computer 3 Ethernet RJ-45 Local network or computer 4 USB Type A External printer, modem, or USB flash drive* 5 RS-232 Comm 1 DB9 female Modem, POS, or local PC * A USB flash drive can be used to collect data or load upgraded files.
  • Page 18: Relay Wiring

    Relay wiring Relay Terminal Description Normally Closed Common Normally Open Normally Closed Common Normally Open Normally Closed Common Normally Open Normally Closed Common Normally Open NOTE: There can be 0, 2, or 4 relays. Dry contact wiring Dry contacts Run Relay (C) Generator #1 Run Relay (N.O.) Run Relay (C)
  • Page 19: Control Drawing 1

    Control drawing 1...
  • Page 20: Control Drawing 2

    Control drawing 2...
  • Page 21 Intentionally Blank...
  • Page 22 Intentionally Blank...
  • Page 23 Intentionally Blank...
  • Page 24 228180003 r2...
