Initial Console Configuration

Initial setup must be completed before the console can be used. This section will show how to
set custom parameters by navigating through the programming options to set up an EVO™ 200 or
EVO™ 400 ATG for the first time.

Touch Screen Calibration

Calibrating the touch screen will enable the console to better recognize the area that you
"touch," so that you can accurately enter in information. The LCD touch screen is calibrated at the
factory when a system is built but it may be necessary to re-calibrate occasionally. To calibrate
the touch-screen function of the display, you must first access the calibration application.
1. From any screen, click Quick Jump>Tools > Calibrate Touchscreen.
2. The console will ask if you are sure that you want to proceed, answer Yes.
3. Follow the on-screen instructions to complete the calibration process.

Console Registration Options

Each console is custom ordered and built to each customer's specifications. That means that all
of the software options needed for your site are installed and tested. Before programming, check
the software options and verify that your purchased options are present.
Pressing QJM > System Tab > System Information Icon > Software Options Tab will give you the
option to view specific details about the system:
• Identification – View to locate the System Serial Number, Ethernet Address (not the same as
IP address), Controller Serial number and Date/Time of manufacture.
• Software Options – Displays the current installed software options.
• About - Provides contact information for Franklin Fueling Systems

Printer Setup

EVO™ 200 and EVO™ 400 ATGs support printing through the USB port or through a network
connection. The following instructions describe the process to detect all available printer and
select a driver:
1. Connect any USB printer to an EVO™ 200 or EVO™ 400 ATG or connect the EVO™ 200 or
EVO™ 400 ATG to the network where the target printer resides.
2. From the Web interface navigate to Settings/Printers
3. Click on the "Search for printers" button
4. Wait for the system to locate the available printers.
5. Locate the desired printer from the list of available printers and click "Search" in the driver
column.
