Getting Started

After the Fuel Management System has been installed, typically your interaction with the system
will be from the LCD display, on-board printer; or using a Web Browser to program and monitor
the console. Remote operation can be performed from a PC, either attached directly through a
network connection or wirelessly through an optional Wifi connection. All of the features of the
console are available through these input / output devices. Also, the console may be set up to
generate and send automated reports to email accounts or print reports at a programmed time.
Occasionally you may need console information, such as model and serial numbers. The model
number is located on the face of the console. The serial number is located on the left side of the
ATG. This label also shows the model number, voltage, manufacturer's address, a warning symbol
and the unit's voltage specifications.

User Interfaces (UI)

LCD Touch Screen Interface

A color LCD touch screen is an optional feature with EVO™ 200 and EVO™ 400 ATGs. This bright
display allows easy viewing in any lighting condition. Console functions are easily accessed
through the LCD screen.

Web Browser Interface

EVO™ 200 and EVO™ 400 ATGs include three methods of establishing a network connection;
an RJ-45 Ethernet port a TYPE-B Mini USB port or the optional Wifi connection. These three
methods allow customers to directly or remotely interface with EVO™ 200 and EVO™ 400 ATGs
using a PC and web browser. This means that console parameters can be modified and status/
alarm reports can be printed from virtually anywhere.

Security Control

EVO™ 200 and EVO™ 400 ATGs include customizable access roles that can be assigned to
individual user to provide secure and control access to the ATGs. The Administrator access level
will allow full access to all features of the EVO™ 200 and EVO™ 400 ATGs. Additional roles can be
configured with preset or customizable access permissions. The customizable roles allow system
administrators the ability to precisely control system access.
