TS-TPI Overview and
Functionality
Tank fuel management can be achieved using an EVO™ 200 or EVO™ 400 ATG and an FE Petro
Turbine Pump Controller (STP- SCI, SCIII, EcoVFC or MagVFC) through Turbine Pump Interface
(TPI). Refer to Tech Update TB1010-04 for connecting to an STP-SCIII controller.
Tank Fuel Management looks at percent (%) full volume of individual tanks and gives priority to
the submersible pump needed to control tank inventories. Additional features and benefits of the
Tank Fuel Management system include:
• Tank Overfill Protection
• Dry Tank Indication
• Automatic pump controller reset
• Clogged Intake Indication
• Pump in Water Indication.
• Use of additional pumps in the same group when de- mand increases
Tank Fuel Management can be used to keep tank levels similar, eliminating the need for a syphon
system. Tank Fuel Management can also be used to pump down one tank to a user defined level,
and then switch over to the other tank for fuel dispensing. In either case, there must be at least
one submersible pump in each tank.

TS-TPI Overview

The TS-TPI programming function allows the controllers to be grouped together and programmed
for specific fuel management options. These options are: On-start leveling, Live Leveling, Priority,
or Alternating. There is also the option to answer Yes or No to Enable Call for Help.

On-start leveling mode

This mode is intended to maintain an equal level of fuel in each tank by giving top priority to
pump controllers associated with the tank containing the most fuel. This forces the pump in the
tank with the highest level of fuel to activate with the next activation of a dispenser switch.
