NOTE: The consoles default IP address is 192.168.168.168. If the PC is normally configured to
acquire an IP address automatically, Alternate Configuration may be used, as mentioned above,
to allow a connection to be enabled without the necessity of reconfiguring the computer each
time it will be used to connect to this console.

Use the Following IP Address

1. If Use the following IP address is selected and the entry boxes contain any information,
record this information for use when console programming is complete.
2. Enter an IP address. For simplicity, make the last segment of the IP one number different
than the IP address of the console. Upon initial setup ONLY, the numbers used in the figure
may be used to configure the TCP/ IP settings of your PC.
3. Leave the DNS information blank.
NOTE: The consoles default IP address is 192.168.168.168. If the PC is normally configured to Use
the following IP address, make sure that all displayed information is recorded and kept prior to
making any changes. It may be necessary to use this information to re-configure the console once
programming is complete.

Check Status of Connection

1. Check the status of your connection by going to the Network Connections window.
2. If the connection status is disabled, enable it by right-clicking on the Local Area Connection
and selecting Enable.
3. Verify link light is lit next to the Ethernet port and RX light is flashing.If technical difficulties
arise, please contact Franklin Fueling Systems Technical Support before proceeding.
NOTE: More information on the Web Browser Interface is located
10
[on page 31] of this manual.
