Connecting a PC or Laptop Computer

To access the console using the Web Browser interface, connect a PC to the console through one
of the available network connections: the Ethernet port, the mini USB port, or the optional Wifi.
If the console is connected to a local network, you can perform this setup from any PC on that
network by using a web browser.
The following instructions are written specifically for the Microsoft Windows® 7 operating
system. For assistance with other operating systems, please contact FFS Technical Support.

Connecting a PC to the Mini USB Port

The network connection via the Mini USB port is designed to provide technicians easy access to
the ATG. By default, the port is setup with DHCP enabled to allow EVO™ 200 and EVO™ 400 ATGs
to assign IP addresses. This is generally the easiest way to connect to EVO™ 200 and EVO™ 400
ATGs.
1. Turn on power to the PC and EVO™ 200 or EVO™ 400 ATG.
2. Using a mini USB cable connect the Mini-B Type-B connector into the mini USB port on the
EVO™ 200 or EVO™ 400 ATG.
3. Connect the Type-A USB connector a USB port on the PC
4. If your PC is setup to "Obtain an IP address automatically," you can open a browser and
connect to the EVO™ 200 or EVO™ 400 ATG using https://192.168.171.171

Connecting a PC to the Ethernet Port

1. Using an Ethernet Crossover, 10 Base-T cable, plug the RJ-45 connector on one end of the
cable into the Ethernet port of the console.
2. Plug the RJ-45 connector on the opposite end of the cable to the Network Interface Card of
the computer.
3. Turn on and log into your PC.
NOTE: You may need to re-configure your TCP/IP settings to allow the computer to communicate
with the console.
NOTE: Some modern laptops have automatically switching Network Interface Cards and as such,
will require the use of a standard cat 6 cable instead of a crossover.
8
