Verify all doors and hoods are properly latched.
4.
Check for proper inflation of the trailer tires. For maximum tire pressures, see Specifications.
5.
Check the wheel lugs. Tighten or replace any lugs that are loose or missing. If
6.
a tire has been removed for axle service or replaced, tighten the lugs, in the
order shown, to the following specifications:
a. Start all lug nuts by hand.
b. First pass tighten to 20-25 ft-lbs (27-33 Nm).
c. Second pass tighten to 50-60 ft-lbs (67-81 Nm).
d. Third pass tighten to 90-120 ft-lbs (122-162 Nm).
Note: After first road use, repeat tightening procedure.
Maximum recommended speed for highway towing is 45 mph (72 km/h). Recommended off-road towing
7.
speed is 10 mph (16 km/h) or less, depending on the terrain.

LIFTING THE UNIT

A central lift point is located on the top of the unit. The
central lift point is connected to a lift structure inside the
unit. Attach a sling or hook directly to the central lift point
only if the devices are in good condition and the equip-
ment being used to raise the unit has sufficient capacity.
For approximate weights, see Specifications. Always
remain aware of people and objects around when moving
or lifting the unit. Keep the doors and hood closed and
locked.
33701 C
Figure 3-13. Central Lift Point Location
MMG75D-100D Operating Manual
3
1
6
2
4
Figure 3-12. Lug
Sequence
Central
Lift Point
02071
Operation
5
00205
35
