Generac Power Systems Mobile Power MMG100 Specifications

Mobile Generator – MMG100 Specifications

ENGINE


John Deere
Prime - 122 hp @ 1800 rpm
o
Standby - 133 hp @ 1800 rpm
o
4 cylinder
o
4.5 L displacement
o
Tier III approved
o

Steel, single wall fuel tank
147 gal. capacity
o
22 hr. run time – full load
o
Fuel tank built into skid of generator set
o

Fuel consumption at prime:
100% - 6.2 gph (23.5 Lph)
o
75% - 4.7 gph (17.8 Lph)
o
50% - 3.1 gph (11.7 Lph)
o

Cooling system capable of operating at 120°F ambient

Low coolant shutdown
 Radiator and oil drains plumbed to exterior

Rubber vibration dampers isolate engine/generator from frame
 Disposable air filter - paper element

Air filter restriction indicator mounted on control panel

60 Hz engine/generator

Electronic isochronous governing

GENERATOR


Marathon Electric
Brushless
o
4 pole
o
Class H insulation
o

Voltage regulation +/- 1% with Marathon SE350 Voltage Regulator

SYSTEM OUTPUT


3 selector switch modes:
Single phase – 120 / 240V Zig Zag
o
Three phase – 120 / 208V Low Wye
o
Three phase – 277 / 480V High Wye
o
 75 kW / 75 kVA – standby, single phase

71 kW / 71 kVA – prime, single phase

86 kW / 107 kVA – standby, three phase

78 kW / 98 kVA – prime, three phase

SYSTEM CONTROLS


Microprocessor-based controller
Backlit, 128x64 pixel resolution display
o
-40°F to 185°F operating temperature range
o
Thermostatically controlled LCD heater
o
Manufactured by Magnum Power Productsllc., a wholly owned subsidiary of Generac Power Systems, Inc.
® PE4045HF285 - turbocharged, diesel engine
®
Phone: 800-926-9768 Fax: 920-361-2214 www.m-p-llc.com
Page 1 of 5
4/12
