To scroll down within the event log, press the Enter () button. The scroll bar will change to blue, signifying it is
active. Press the ▲ or  buttons to scroll up or down in the event log. When finished, press the Enter () button again.
Input/Output Tab
The Input/Output (I/O) tab shows a list of digital inputs and outputs connected to the controller, whether they are
active and the current state (open/closed status) of the input and output.
Schedule Tab
The Scheduler tab shows the current configuration and status of the scheduler, located below the generator summary.
The maintenance configuration status and time remaining until an alarm, electrical trip or shutdown will be displayed
at the bottom of the screen. The lamp(s) to the left shows the configuration status of the maintenance alarm, not the
alarm condition.
