Generac Power Systems Mobile Power MMG235 Specifications

Mobile Generator – MMG235 Specifications

ENGINE


John Deere
Prime - 286 hp @ 1800 rpm
o
Standby - 315 hp @ 1800 rpm
o
6 cylinder
o
6.8 L displacement
o
Tier III approved
o

Steel, single wall fuel tank
342 gal. capacity
o
313 usable gallons
o
21 hr. run time – full load
o
Fuel tank built into skid of generator set
o

Fuel consumption at prime:
100% - 15.2 gph (57.5 Lph)
o
75% - 11.4 gph (43.2 Lph)
o
50% - 7.6 gph (28.8 Lph)
o
 Cooling system capable of operating at 120°F ambient

Low coolant shutdown

Radiator and oil drains plumbed to exterior

Rubber vibration dampers isolate engine/generator from frame

Disposable air filter - paper element
 Air filter restriction indicator mounted on control panel

60 Hz engine/generator

Electronic isochronous governing

GENERATOR

 Marathon Electric
Brushless
o
4 pole
o
Class H insulation
o

Voltage regulation +/- 1% with Marathon SE350 Voltage Regulator

SYSTEM OUTPUT


Link / Reconnect Board:
Three phase – 120 / 208V Low Wye
o
Three phase – 277 / 480V High Wye
o

204 kW / 255 kVA – standby, three phase

186 kW / 233 kVA – prime, three phase

SYSTEM CONTROLS


Microprocessor-based controller
Backlit, 128x64 pixel resolution display
o
-40°F to 185°F operating temperature range
o
Thermostatically controlled LCD heater
o
Manufactured by Magnum Power Products LLC., a wholly owned subsidiary of Generac Power Systems, Inc.
® PE6068HF485 - turbocharged, diesel engine
®
Phone: 800-926-9768 Fax: 920-361-2214 www.m-p-llc.com
2 3 5
Page 1 of 4
4/12
