General Information
GENERAC MODEL MMG100D MMG100D Super Start
Engine
Make/Brand.............................................................................John Deere..............................John Deere
Model ......................................................................................PE4045HFG92 ........................PE4045HFG92
EPA Tier ..................................................................................4i .............................................4i
Horsepower - Prime hp (kW) .................................................121 (90) ...................................121 (90)
Horsepower - Standby hp (kW) .............................................133 (99) ...................................133 (99)
Operating Speed rpm .............................................................1800 ........................................1800
3
Displacement in (L) ..............................................................275 (4.5) ..................................275 (4.5)
Cylinders - qty .........................................................................4 ..............................................4
Fuel Consumption - 100% Prime gph (Lph) .........................6.2 (23.5) .................................6.2 (23.5)
Battery Type - Group Number .................................................24 ............................................24
Battery Voltage (quantity per unit)...........................................12V (1) ....................................12V (1)
Battery Rating .........................................................................720 CCA..................................720 CCA
Generator
Make/Brand.............................................................................Marathon Electric ....................Marathon Electric
Model ......................................................................................362PSL1606 ...........................363PSL1607
Type, Insulation.......................................................................Brushless, H ............................Brushless, H
Generator Set (Engine/Generator)
3Ø - Standby kW (kVA) ..........................................................86 (107) ...................................88 (110)
Amps - 3Ø Standby 480V (208V) A ........................................129 (297) .................................132 (305)
3Ø - Prime kW (kVA) ..............................................................78 (98) .....................................80 (100)
Amps - 3Ø Prime 480V (208V) A............................................118 (272) .................................120 (278)
1Ø - Standby kW (kVA) ..........................................................75 (75) .....................................78 (78)
Amps - 1Ø Standby - 240V A .................................................313 ..........................................325
1Ø - Prime kW (kVA) ..............................................................71 (71) .....................................72 (72)
Amps - 1Ø Prime - 240V A .....................................................296 ..........................................300
Frequency Hz..........................................................................60 ............................................60
Power Factor...........................................................................1 (1Ø), 0.8 (3Ø) .......................1 (1Ø), 0.8 (3Ø)
Sound dB(A) 23 ft @ prime ...................................................68 ............................................68
Weights
Dry Weight, Skid Mounted lbs (kg).........................................3780 (1714) .............................3930 (1782)
Operating Weight, Skid Mounted lbs (kg) ..............................4740 (2150) ............................4890 (2218)
Dry Weight, Trailer Mounted* lbs (kg) ....................................4480 (2032) .............................4630 (2100)
Operating Weight, Trailer Mounted* lbs (kg) ..........................5440 (2467) .............................5590 (2535)
*Standard trailer only. Consult factory for custom trailer weights.
Capacities
Fuel Tank Volume gal (L)........................................................165 (625) .................................165 (625)
Usable Fuel Volume gal (L) ....................................................151 (572) .................................151 (572)
Coolant (incl. engine) qt (L) ....................................................22.0 (20.8) ...............................22.0 (20.8)
Oil (incl. filter) qt (L) ................................................................15.5 (14.7) ...............................15.5 (14.7)
Maximum Run Time hrs .........................................................24 ............................................24
AC Distribution
Circuit Breaker Size ................................................................400 ..........................................400
Voltage Selection ....................................................................3 position switch (lockable) .....3 position switch (lockable)
Voltage Regulation..................................................................+/- 0.5%...................................+/- 0.5%
Voltages Available 1Ø .............................................................120, 139, 208, 220, 240, 277 ..120, 139, 208, 220, 240,
277
Voltages Available 3Ø .............................................................208, 220, 440, 480 ..................208, 220, 440, 480
Trailer
Number of Axles......................................................................1 ..............................................1
Capacity - Axle Rating lbs (kg) ...............................................6000 (2722) .............................6000 (2722)
Tire Size in..............................................................................15 ............................................15
Brakes.....................................................................................Surge.......................................Surge
Hitch - Standard ......................................................................3'' ring ......................................3'' ring
Maximum Tire Pressure psi ....................................................65 ...........................................65
Specifications are subject to change without notice.
