MDT Technologies SCN-P360D3.02 Technical Manual page 57

Technical Data
Covered area (Diameter)
Movement *
Presence *
Sensitivity
Angular coverage
Range of light sensor
Measurement range temperature
Specification KNX interface
Available application software
Permitted wire gauge
KNX busconnection terminal
Power supply
Power consumption KNX bus typ.
Operation temperature range
Enclosure
Dimensions (W x H x D)
* at maximum mounting height of 4m (See images below).
Covered area SCN-P360x4.02
Examplary circuit diagram SCN-x360xx.02
MDT technologies GmbH
•
51766 Engelskirchen
Tel.: + 49 - 2263 - 880 Fax: + 49 - 2263 - 4588
•
Stand: 0817
MDT Presence Detector
SCN-P360D4.02
SCN-P360K4.02
16m
8m
adjustable in 10 steps
360°
5 - 1000 Lux
-
TP-256
ETS 4/5
0,8mm Ø, solid core
KNX bus
<0,3W
0 to + 40°C
IP 20
85mm x 85mm x 38mm
•
Papiermühle 1
• •
knx@mdt.de www.mdt.de
SCN-P360D3.02 SCN-G360D3.02
SCN-P360K3.02 SCN-G360K3.02
11m
5m
adjustable in 10 steps adjustable in 10 steps
360°
5 - 1000 Lux
-
TP-256
ETS 4/5
0,8mm Ø, solid core 0,8mm Ø, solid core
KNX bus
<0,3W
0 to + 40°C
IP 20
92mm x 92mm x 32mm
75mm x 75mm x 35mm
Covered area SCN-x360x3.02
Covered area SCN-P360x1.01
SCN-P360D1.01
11m
5m 3-4m
fixed, not adjustable
360° 360°
5 - 1000 Lux 5 - 1000 Lux
-10 to +50C
TP-256 TP-256
ETS 4/5 ETS 4/5
0,8mm Ø, solid core
KNX bus KNX bus
<0,3W <0,3W
0 to + 40°C 0 to + 40°C
IP 20 IP 20
43mm x 43mm x 30mm
DIN EN ISO 9001
TAW Cert
Zert.Nr.1905606
N
5m
-
