Technical Manual Presence Detector SCN-P/G360XX.02

4.10 Temperature

Only for Glass-Presence detectors: SCN-G360D3.02, SCN-G360K3.02
The following picture shows the available settings:
Figure 30: Settings - Temperature measurement
The temperature measurement can be used to measure the temperature in the room and send it to
the bus. The temperature can be sent to the bus either at an adjustable change or cyclically (at fixed
intervals).
The measured temperature can be shifted up or down using the "Correction value for sensor"
parameter..
The following table shows the available communication object:
Number Name
Temperature – Measured
110
value
Table 29: Communication object - Temperature measurement
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
51
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
51
Length Usage
2 Byte Sending the measured value
