- Page 1 FLT-01 User Manual Scan for more information V 1 . 0...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Precautions ................3 Specifications .................. 4 Dimensional drawing ............... 5 Components ..................6 Assembly ..................7 Operations ..................10 Reset Procedure ................10 Troubleshooting ................11 Have any queries? Our expert engineers are here to help! sales@progressiveautomations.com progressiveautomations.com 1-800-676-6123... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS When installing and using your Progressive Automations linear actuator, basic safety precautions should always be followed. Please read all safety precautions thoroughly and be familiar with all functions of the product before use. Apply all other relevant precautions when operating electrical and moving mechanical devices. -
Page 4: Specifications
SPECIFICATIONS SPECIFICATIONS Specification Description Input Voltage 120 VAC, 60 Hz Output Voltage 24VDC Stroke (movement) 25.5" Height Range (without tabletop) 23.1" - 48.6" Weight Capacity (load) 180 lbs No Load Speed 1.57"/s Full Load Speed 1.18"/s Duty Cycle 10% (2 minutes on, 18 minutes off) Operating Noise <... -
Page 5: Dimensional Drawing
DIMENSIONAL DRAWING Note: All dimensions are listed in inches. DIAGRAM P a g e | 5... -
Page 6: Components
COMPONENTS IMPORTANT The drawings below are for reference only and may be slightly different from the physical product. Please contact us if you have missing or damaged components. TOOLS YOU WILL NEED Included Allen Wrench (B4) Phillips Head Screwdriver and/or Tape Measure Electric Driver Part... -
Page 7: Assembly
ASSEMBLY STEP 1: ATTACH THE BRACKET TO THE TABLETOP Method A: Progressive Desk tabletop Line up the Bracket (A1) with the predrilled holes on the underside of the tabletop and insert the M6x18 machine screws and washers included with your tabletop. Use the Allen Wrench included with your tabletop to tighten each machine screw to secure the bracket to the tabletop. - Page 8 STEP 2: INSTALL THE LEG TO THE BRACKET Insert the Leg (A2) into the Bracket and align the holes. Secure with 4x M6x10 Machine Screws (B2) using Allen Wrench (B4). STEP 3: SECURE AND CONNECT THE REMOTE AND CONTROL BOX Place the Remote (A4) and Control Box (A5) at the desired location and mark all four holes’...
- Page 9 STEP 4: CONNECT CABLES Connect the Remote (A4) to the HS port of the Control Box (A5). Connect the Power Cord (A6) to the Control Box (A5). Connect the Cable from the Leg (A2) to the M1 Port of the Control Box (A5). Connect the Extension Cable (A7) to the Leg cable if the Leg Cable is not long enough to reach the Control Box (A5).
-
Page 10: Operations
OPERATIONS NORMAL OPERATION Using the wired remote, press and hold the 'Up' button to raise the table lift. To lower the table lift, press and hold the 'Down' button. The 'Up' and 'Down' buttons are momentary controlled, when they are released, the table lift will stop immediately. -
Page 11: Troubleshooting
TROUBLESHOOTING Troubleshooting Guide Problem Possible Cause Corrective Action Remote LED is off. Low power Press any button on the remote and LED will activate. mode activated Connection Disconnect and reconnect the RJ-45 remote connector. Ensure issue connection is secure and cable is not damaged. Table lift does not Limit switch Follow "Setting Limit Switches"...
