- Page 1 FLT-21 User Manual Scan for more information V 1 . 0...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Precautions ................3 Specifications .................. 4 Dimensional drawing ............... 5 Parts List ..................6 Assembly & Installation ..............7 Operations ..................15 Troubleshooting ................17 Have any queries? Our expert engineers are here to help! sales@progressiveautomations.com progressiveautomations.com 1-800-676-6123 P a g e | 2... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS When installing and using your Progressive Automations table lift, basic safety precautions should always be followed. Please read all safety precautions thoroughly and be familiar with all functions of the product before use. Apply all other relevant precautions when operating electrical and moving mechanical devices. -
Page 4: Specifications
SPECIFICATIONS SPECIFICATIONS Specification Description Input Voltage 100VAC-240VAC Output Voltage 24VDC Stroke (movement) 19.3" Height Range (without tabletop) 27.6" - 46.9" Base Width 36.7" - 54.7" Minimum Tabletop Size 42" x 20" Weight Capacity (load) 220 lbs (evenly distributed) 1.00”/s No Load Speed 0.59”/s Full Load Speed Duty Cycle... -
Page 5: Dimensional Drawing
DIMENSIONAL DRAWING Note: All dimensions are listed in inches. DIAGRAM P a g e | 5... -
Page 6: Parts List
PARTS LIST IMPORTANT The drawings below are for reference only and may be slightly different from the physical product. Please contact us if you have missing or damaged components. Part Part Part M6x16 Screws Adaptor Mount Left Frame End Power Adaptor ST4.2x25 Tabletop Screws Right Frame End... -
Page 7: Assembly & Installation
ASSEMBLY & INSTALLATION STEP 1: LEG AND FRAME END ASSEMBLY A1 (x2) A2 (x2) A3 (x2) B1 (x8) B8 (x1) Left Frame End Right Frame End M6x10 Screws Allen Key • Place 1x Leg (A1) vertically with the motor side facing down. •... - Page 8 STEP 2: ATTACH SIDE BRACKET A4 (x2) B2 (x4) B8 (x1) Side Bracket M6x12 Screws Allen Key • Flip the assembly from Step 1 • Align 1x Side Bracket (A4) to the Leg and Frame End assembly. • Use the Allen Key (B8) to secure the Side Bracket (A4) with 2x M6x12 Screw (B2). •...
- Page 9 STEP 3: INSTALL CENTER RAILS A5 (x2) B8 (x1) Center Rail Allen Key With the Allen Key (B8), loosen the preinstalled screws at the center of all Frame Ends (A2 and A3). Insert Center Rail (A5) into the Left and Right Frame Ends (A2 and A3). Do not tighten the screws to allow size adjustment in a later step.
-
Page 10: Step 4: Attach Feet
STEP 4: ATTACH FEET A6 (x2) B3 (x8) B8 (x1) Foot M6x16 Screws Allen Key • Attach 1x Foot (A6) to Leg (A1) using 4x M6x16 Screws (B3). Tighten the screws with the Allen Key (B8). • Repeat for second Leg (A1). STEP 5: SECURE DESK FRAME TO TABLETOP A8 (x1) Adaptor Mount... - Page 11 FOR PROGRESSIVE DESK TABLETOPS • Place the Progressive Desk Tabletop on a soft flat surface with the threaded inserts facing upwards. If you have a hard surface, place the foam sheet included in the tabletop packaging on the surface to protect your tabletop. •...
- Page 12 FOR THIRD-PARTY TABLETOPS B4 (x8) ST4.2x25 Tabletop Screws • Place the desk frame on top of the tabletop at your desired location. Make sure the motor cords attached to the Legs (A1) are not pinched between the frame and the tabletop. •...
- Page 13 STEP 6: INSTALL REMOTE AND CONNECT CABLES A7 (x1) A9 (x1) A10 (x1) A11 (x1) A12 (x1) B5 (x6) B6 (x2) B7 (x6) Remote Power Adaptor Power Cable Switch Cord Extension Cord ST4.2x13 ST4.2x25 Cable Tie Self-Drilling Screws (B5, B6) Hard Materials: It is recommended that an Electric Driver is used to install the Self-Drilling Screws (B5, B6) into any Hardwood, Bamboo, Epoxy Tabletops or similar.
- Page 14 • Connect Power Cable (A10) and Switch Cord (A11) to Power Adaptor (A9). • Slide the Power Adaptor (A9) into Adaptor Holder (A8). • Plug the Switch Cord (A11) into the DCIN port on Remote (A7). • Organize the cables as needed using the Cable Ties (B7). ST4.2x12 Screws (B5) can be used to secure Cable Clips (B7) onto tabletop.
-
Page 15: Operations
OPERATIONS REMOTE BUTTONS Remote Button Control Press and hold to move desk frame up Press and hold to move desk frame down Memory Position 1 - Press once and the desk will travel to the saved position. Memory Position 2 - Press once and the desk will travel to the saved position. Memory Position 3 - Press once and the desk will travel to the saved position. -
Page 16: Safety Lock
SAFETY LOCK When Safety Lock is enabled, the remote will no longer be responsive to user input until the function is disabled. Turn on Safety Lock Function: buttons for 3 seconds or until “LOC” or “LoC” appears on the display. Simultaneously press and hold the , and Safety lock function is now enabled. -
Page 17: Troubleshooting
TROUBLESHOOTING Common Problems Problem Possible Cause Corrective Action Table lift does not Connection Disconnect and reconnect the cables to the remote. Ensure the cables are move when motion issue not damaged and that all connections are secure. control buttons are pressed.
