- Page 1 CONTACTLESS ENCODERS WITH SSI INTERFACE USER INFORMATION Sense it! Connect it! Bus it! Solve it!
-
Page 2: General Information
M = 0.6…0.8 Nm and thorough maintenance guarantee the troublefree and safe operation of these de- vices. Hans Turck GmbH & Co. KG • Tel. +49 208 4952-0 • Fax +49 208 4952-264... -
Page 3: Table Of Contents
Commissioning ..............6 Mounting ................7 SSI process data ..............8 Parametrization via teach function ........8 Parametrization via PACTware™ and IODD ..... 9 Mounting accessories and positioning elements ..11 10 Technical data ................ 13 more@turck.com • www.turck.com • 2014/11... -
Page 4: Type Code
(digit 1 and 2) H1 Male connector M12 x 1 Note The sensor, mounting accessories and posi- tioning elements are individually available or as a kit. Hans Turck GmbH & Co. KG • Tel. +49 208 4952-0 • Fax +49 208 4952-264... -
Page 5: Ssi Interface Description
This makes precise and immune to interferences. Not the SSI encoder compatible with virtually all only process data is transmitted via SSI tel- major SSI masters. egram but also diagnostic bits. more@turck.com • www.turck.com • 2014/11... -
Page 6: Commissioning
200 µs, regard- less of the cycle time. On selecting the SSI master, note that a jitter of < 5 µs is required in synchronous mode. Hans Turck GmbH & Co. KG • Tel. +49 208 4952-0 • Fax +49 208 4952-264... -
Page 7: Mounting
5 Remove mounting aid on the rotating part. Screw tight with 6 The protective Al cover and the shield- the three screws until you get a stable ing plate SP1-QR24 can be used option- and protected unit ally more@turck.com • www.turck.com • 2014/11... -
Page 8: Ssi Process Data
15 s, power and status LED flash the following parameter are restored: CW rotation, zero point, multiturn error for 15 s alternately (delete), multiturn counter (zero) Hans Turck GmbH & Co. KG • Tel. +49 208 4952-0 • Fax +49 208 4952-264... -
Page 9: Parametrization Via Pactware™ And Iodd
You can download PACTware™, the IODD- PACTware™, activate the "IODD_IOL_Ri- interpreter and the encoder IODD-file from QR24..zip" file with the IODD-interpreter and www.turck.com. Once you have installed update the device catalog in PACTware™. 8.2 Set Parameters The following encoder parameters can be set in PACTware™:... - Page 10 ) This parameter is not adjustable via "Easy teach function". 8.4 Factory setting SSI-Process data … Error Multiturn Singleturn Bit 24…Bit 22 Bit 21…Bit 16 Bit 15…Bit 0 Hans Turck GmbH & Co. KG • Tel. +49 208 4952-0 • Fax +49 208 4952-264...
-
Page 11: Mounting Accessories And Positioning Elements
RA7-QR24 Reducing bushing, for Ø 1/4" 120° shafts ø 3.2 ø 52 RA8-QR24 Blanking plug for positioning ø 42 element ø 28 ø 24 MT-QR24 Mounting aid for optimal align- ment of positioning element more@turck.com • www.turck.com • 2014/11... - Page 12 ø 1/4“ for Ø 1/4" shafts ø 3.2 ø 52 ø 42 P8-Ri-QR24 Positioning element with blank- ing plug ø 3.2 ø 52 ø 42 Hans Turck GmbH & Co. KG • Tel. +49 208 4952-0 • Fax +49 208 4952-264...
-
Page 13: Technical Data
138 years to SN 29500 (Ed. 99) 40 °C LEDs Operating voltage indication LED green Measuring range indication LED, yellow, yellow flashing Fault indication LED red Miscellaneous Included in scope of supply mounting aid MT-QR24 more@turck.com • www.turck.com • 2014/11... - Page 14 WORLDWIDE HEADQUARTERS Hans Turck GmbH & Co. KG Witzlebenstr. 7 45472 Muelheim an der Ruhr Germany Your Global Tel. +49 208 4952-0 Fax +49 208 4952-264 Automation Partner! E-Mail more@turck.com Internet www.turck.com D102003 2014/11 *D102003ßß1411*...
