COLD WATER INLET

TO COMPLY WITH UK WATER SUPPLY REGULATIONS
A SINGLE CHECK VALVE MUST BE FITTED
BEFORE CONNECTING,
THOROUGHLY FLUSHED OUT TO ENSURE THAT FOREIGN
MATTER DOES NOT BLOCK OR ENTER THE SOLENOID VALVE
The boiler must be connected to a potable water supply using the food
grade hose provided, or rigid 15mm pipe in a manner which complies
with UK water regulations via an appropriate isolating valve. Always
use the new hose supplied. Do not reuse old hoses. Do not use red or
blue washing machine hoses as these will impart an unpleasant taste
to the water. The water supply must provide a constant pressure of
between 20 KPa and 1000 KPa (0.2 to 10 Bar).
If the water supply contains solids in suspension it is recommended
that an "in line" water filter is fitted in the pipe work. Problems caused
by scale and sediment are not covered by the warranty.

ACCESS INSTRUCTIONS

Access to the internals of the machine is gained by the removal
of the front panel. It is advised to remove the cup stand drawer
before removing front panel. To remove the drawer pull the latch up
underneath the cup stand and slide the stand out. Calomax advise
to place the drawer back in its housing after the front panel has been
screwed back into place to avoid damage. When replacing the drawer
ensure there are no wires trapped behing the drawer to avoid pulling
them out.
THE SUPPLY
.
PIPE MUST
Page 5
BE
