Summary of Contents for Calomax Quantum
- Page 1 Quantum Counter-top Catering Water Boiler INSTALLATION, OPERATION AND MAINTENANCE MANUAL Read these instructions thoroughly before commencing installation or Issue 3 - DCR 674:8/6/05 undertaking maintenance work. TEL: 0113 249 6681 FAX: 0113 235 0358 www.calomax.co.uk...
-
Page 2: Table Of Contents
CONTENTS PARTS IDENTIFICATION . PAGE 1 PLANNING THE INSTALLATION . Water Requirements Electrical Requirements Installation Location Vent/Overfl ow Pipe Requirements INSTALLATION COMMISSIONING . USER INSTRUCTIONS Cleaning Service Indicator Light MAINTENANCE 6.1 Draining Down The Boiler 6.2 Scale 6.2.1 Checking the Extent of Scale Formation . 6.2.2 De-Scaling 6.3 Replacing the Element or Thermistor 6.4 Replacing the Main Printed Circuit Board and Triac PCB. -
Page 3: Parts Identification
PAGE 1 ISSUE 3... -
Page 4: Planning The Installation
2. PLANNING THE INSTALLATION Installation Location All installation and maintenance work must be Ensure the counter top is of suitable construction carried out by competent persons. to support the working weight of the boiler. See Fig. 1 2.1 Water Requirements To comply with recommendations from the health and safety executive it is important that due The unit is designed to be connected to a cold... -
Page 5: Installation
The button will only be useable when the key switch is in the ‘ON’ position and illuminated solid green colour, 3. All Quantum machines are pre-wired with a 13A plug indicating that water is up to temperature. Due caution and lead for use with a 13 A socket. -
Page 6: Cleaning
It is very important that the lid assembly is fi tted the correct way round for the condenser to work For ease of maintenance the Quantum water effectively. See label on top of lid boiler is fi tted with a drain valve at the rear of IMPORTANT. -
Page 7: Replacing The Element Or Thermistor
Printed Circuit Board by Calomax must be fi tted. (PCB) that water is covering the element whether or not water is present. In this situation the PCB 3. -
Page 8: Adjusting The Water Temperature Set Point
The unit can be used normally while the The temperature potentiometer (Pot) is pre-set service light is fl ashing at Calomax and will only require adjustment in LED’s fi tted to the main PCB indicate the exceptional circumstances, the adjustment Pot operation of the solenoid and element. -
Page 9: Wiring Schematic
Wiring Schematic for Calomax Quantum Water Boiler using v10 board TRIAC PCB YELLOW / GREEN BLACK BLACK EARTH EARTH ON EARTH ON BASE CASING ON BODY LEVEL SENSORS HIGH NORMAL THERMAL CUTOUT +12Vdc (BROWN) 0Vdc (ORANGE) ELEMENT PINK BROWN HOT WATER OUTLET...
