DEMO MANUAL DC2161A

PARTS LIST

ITEM QTY REFERENCE
1 1 C1
2 0 C2
3 1 C3
4 1 C4
5 1 D1
6 1 D2
7 10 E1-E10
8 2 JP1, JP2
9 1 JP3
10 4 J1, J2, J3, J4
11 1 Q1
12 1 R1
13 1 R2
14 1 R3
15 0 R4
16 1 R5
17 1 R6
18 1 R7
19 1 R8
20 1 R9
21 2 R10, R11
22 3 SHUNTS AS
SHOWN ON ASSY
DWG
23 4 MH1-MH4
DC2161A-A Additional Demo Board Circuit Components
1 1
2 1 U1
DC2161A-B Additional Demo Board Circuit Components
1 1
2 1 U1
4
PART DESCRIPTION
CAP., X7R, 0.1µF 25V, 10%, 0603
CAP., 0402
CAP., TANT, 100µF 25V, 20%, 7343
CAP., X7R, 0.082µF 16V, 10%, 0402
DIODE, SUPPRESSORS,600W, SMB-DIODE
LED, GREEN, LED-ROHM-SML-010
TURRET, TESTPOINT 0.064"
HEADER, 2mm SINGLE 3POS
HEADER, 2mm DOUBLE 3POS
JACK, BANANA
MOSFET, DUAL-CH, 60V, SO8-POWERPAK
RES., CHIP, 10, 1/16W, 1%, 0603
RES., SENSE, 0.015, 1/4W, 1%, 1206
RES., CHIP, 10, 1/16W, 1%, 0402
RES., 0402
RES., CHIP, 3.32kΩ, 1/16W, 1%, 0603
RES., CHIP, 1.24MΩ, 1/8W, 1%, 0805
RES., CHIP, 12.4kΩ, 1/16W, 1%, 0402
RES., CHIP, 24.9kΩ, 1/16W, 1%, 0402
RES., CHIP, 75kΩ, 1/16W, 1%, 0402
RES., CHIP, 100kΩ, 1/16W, 5%, 0402
SHUNT, 2mm CTRS.
STAND-OFF, NYLON 0.25"
DC2161A-GENERAL BOM
I.C., MICROPOWER HOT SWAP CONTROLLER, MS12
DC2161A-GENERAL BOM
I.C., MICROPOWER HOT SWAP CONTROLLER, MS12
MANUFACTURER/PART NUMBER
MURATA, GRM188R71E104KA01D
OPT
AVX, TAJE107M025RNJ
MURATA, GRM155R71C823KA88D
FAIRCHILD SEMI., SMBJ24CA
ROHM, SML-010FTT86
MILL-MAX, 2308-2-00-80-00-00-07-0
SULLINS, NRPN031PAEN-RC
SAMTEC, TMM-103-02-L-D
KEYSTONE, 575-4
VISHAY SILICONIX, Si7960DP-T1-GE3
VISHAY, CRCW060310R0FKEA
VISHAY, WSL1206R0150FEA
VISHAY, CRCW040210R0FKED
OPT
VISHAY, CRCW06033K32FKEA
VISHAY, CRCW08051M24FKEA
VISHAY, CRCW040212K4FKED
VISHAY, CRCW040224K9FKED
VISHAY, CRCW040275K0FKED
VISHAY, CRCW0402100KJNED
SAMTEC, 2SN-BK-G
KEYSTONE, 8831 (SNAP ON)
LINEAR TECH., LTC4231IMS-1
LINEAR TECH., LTC4231IMS-2
dc2161af
