4-10 PC Health Status

This section shows the status of your CPU, Fan, and overall system.
This is only available when there is Hardware Monitor function onboard.
VCC3V
Vcore
VGFX
VBS3V
CPU Temp.
System Temp.
↑↓→← :Move Enter:Select
↑↓→←
F5:Previous Values
Current CPU Temperature/Current System Temp Vcore/VGFX/VBS3V
This will show the CPU/Graphics/System voltage chart.

4-11 Load Optimized Defaults

When you press <Enter> on this item, you get a confirmation dialog box with a message
similar to:
Load Optimized Defaults ( Y/N )? N
Press <Y> to load the default values that are factory settings for optimal system operation
performance.
Phoenix-AwardBIOS CMOS Setup Utility
PC Health Status
+/ -/PU/PD:Value
F6:Fail-Safe Defaults
3.31V
1.15V
1.05V
Menu Level ►
3.29V
63 C 0
43 C
0
F10:Save ESC:Exit
F7:Optimized Defaults
57
Item Help
F1:General Help
